Page 1
UMC-GA1SC1T-SM-FX UNMANAGED ETHERNET MEDIA CONVERTER UNMANAGED ETHERNET MEDIENKONVERTER CONVERTISSEUR DE MÉDIA ETHERNET NON GÉRÉ アンマネージドイーサネット用メディアコンバーター Quick Start Guide V1.0 Quick-Start Anleitung Guide de Démarrage Rapide クイックスタートガイド...
Page 2
Thank you for choosing the Unmanaged Ethernet Media Converter. This guide is designed to familiarize you with the layout of the media converter and describes how to deploy it in your network. UMC-GA1SC1T-SM-FX Accessory Power Adapter x1 NOTE: The accessory may vary from illustration, please prevail in kind.
Hardware Overview Front Panel Ports TP/LNK FX/LNK RJ45 Ports Description RJ45 10/100/1000Base-T RJ45 port for Ethernet connection SC port for duplex SC single mode or multimode ber connection Front Panel LEDs TP/LNK FX/LNK TP/LNK FX/LNK PWR...
Page 4
LEDs State Description The link through the TP port is Green successfully established. TP/LNK The TP port is actively sending or Blinking Green receiving data. The TP port link is down. The TP port is operating at Green 1000Mbps. The TP port is operating at 10M/ 100Mbps.
Bottom Panel DIP Switch Function State Description Disable LFP Function Enable Disable ALS Function Enable Disable FX Reset Enable FX 1000M FX Speed Set FX 100M/1000M NOTE: 1. LFP (Link Fault Pass Through) Function: If enabled, when a device is connected to the converter and the TP/ ber line loses the link, the converter's ber will disconnect the link of transmit.
Installation Requirement Do not operate it in an area that exceeds an ambient temperature of 50°C. The installation site should be well-ventilated. Be sure that the converter is level and stable to avoid any hazardous conditions. Do not install the equipment in a dusty environment. The installation site must be free from leaking or dripping water, heavy dew, and humidity.
Page 7
Rack Mounting (Used with MFMC-12DP 12 Slots Mini Media Converter Chassis) 1. Install the mounting brackets on the left rear side of the converter with two screws. NOTE: Please purchase the MFMC-12DP 12 Slots Mini Media Converter Chassis on fs.com...
Page 8
2. Install the converters onto the chassis in sequence ( rst install the lower level, then the upper level). Each converter can be xed tightly in the chassis by two screws. 3. Place the chassis into the rack. Align the brackets of the chasis to the side holes on the rack and secure the chassis to the rack with screws.
Page 9
Connecting the RJ45 Port 1. Connect a network cable to the RJ45 port of the converter. S 3 9 0 0 - 2 4 T 4 S 2. Connect the other end of the network cable to the network device (switch, PC, router, etc.).
Page 10
Connecting the SC Port Connect one end of a ber optic cable to the SC port and the other end to the ber network. TX and RX must be paired at both ends. NOTE: The converter is installed with the transceiver with SC connector as default.
Connecting the Power Desk Mounting: Connect one end of the power adapter to the converter and the other end to the power source. Then verify that the power LED lights up.
0 / 6 0 H Z - 2 4 0 V 5 A C 1 0 0 I N P U T : F U S E :3 .1 F A N O F F Rack Mounting: Connect the chassis power cord to the chassis and turn on the power switch on the back of the chassis.
Contact Us https://www.fs.com/contact_us.html Product Warranty FS ensures our customers that for any damage or faulty items due to our workmanship, we will o er a free return within 30 days from the day you receive your goods. This excludes any custom-made items or tailored solutions.
Page 14
Vielen Dank, dass Sie sich für den Unmanaged Ethernet Medienkonverter entschieden haben. Diese Anleitung soll Sie mit dem Aufbau des Medienkonverters vertraut machen und beschreibt, wie Sie ihn in Ihrem Netzwerk einsetzen. UMC-GA1SC1T-SM-FX Zubehör Netzteil x1 HINWEIS: Das Zubehör kann von der Abbildung abweichen, bitte...
Page 15
Hardware-Übersicht Ports an der Vorderseite TP/LNK FX/LNK RJ45 Ports Beschreibung 10/100/1000Base-T RJ45-Port für die Ethernet- RJ45 Verbindung SC-Port für Duplex SC Singlemode- oder Multimode- Glasfaseranschluss LEDs an der Vorderseite TP/LNK FX/LNK TP/LNK FX/LNK PWR...
Page 16
LEDs Status Beschreibung Die Verbindung über den TP-Port wurde Grün erfolgreich hergestellt. TP/LNK Der TP-Port überträgt oder empfängt Blinkt grün aktiv Daten. Die TP-Port-Verbindung ist ausgefallen. Grün Der TP-Port arbeitet mit 1000 Mbps. Der TP-Port arbeitet mit 10M/100 Mbps. Die Verbindung über den Glasfaser- Grün Port wurde erfolgreich hergestellt.
Unterseite (DIP-Schalter) DIP-Schalter Funktion Status Beschreibung Deaktivieren LFP-Funktion Aktivieren Deaktivieren ALS-Funktion Aktivieren Deaktivieren FX-Reset Aktivieren FX 1000M FX-Geschwindigkeit seinstellung FX 100M/1000M HINWEIS: 1. LFP (Link Fault Pass Through) Funktion: Wenn diese Funktion aktiviert ist, unterbricht die Faser des Konverters die Verbindung, wenn ein Gerät an den Konverter angeschlossen ist und die TP/Faserleitung die Verbindung verliert.
Page 18
Installationsanforderungen Betreiben Sie das Gerät nicht in einem Bereich, in dem die Umgebungstemperatur 50 °C übersteigt. Der Aufstellungsort muss gut belüftet sein. Achten Sie darauf, dass der Konverter eben und stabil steht, um gefährliche Situationen zu vermeiden. Installieren Sie das Gerät nicht in einer staubigen Umgebung. Der Aufstellungsort muss frei von austretendem oder tropfendem Wasser, starkem Tau und Feuchtigkeit sein.
Page 19
Rack-Montage (Beispiel anhand des MFMC-12DP 12 Slots Mini-Medienkonverter-Chassis) 1. Montieren Sie die Montagewinkel mit zwei Schrauben an der linken Rückseite des Konverters. HINWEIS: Das MFMC-12DP 12 Slots Mini-Medienkonverter-Chassis ist auf fs.com erwerblich.
Page 20
2. Montieren Sie die Konverter nacheinander auf das Chassis (zuerst die untere Ebene, dann die obere Ebene). Jeder Konverter kann mit zwei Schrauben fest im Chassis xiert werden. 3. Setzen Sie das Chassis in das Rack ein. Richten Sie die Montagewinkel des Chassis an den seitlichen Löchern des Racks aus und befestigen Sie das Chassis mit Schrauben am Rack.
Page 21
Anschließen des RJ45-Ports 1. Schließen Sie ein Netzwerkkabel an den RJ45-Port des Konverters an. S 3 9 0 0 - 2 4 T 4 S 2. Schließen Sie das andere Ende des Netzwerkkabels an das Netzwerkgerät (Switch, PC, Router usw.) an.
Anschließen des SC-Ports Schließen Sie ein Ende eines LWL-Kabels an den SC-Port und das andere Ende an das Glasfasernetzwerk an. TX und RX müssen an beiden Enden gepaart sein. HINWEIS: Der Konverter ist standardmäßig mit einem SC-Port- Transceiver installiert. Anschließen der Stromversorgung...
Page 23
Tisch-Montage: Schließen Sie das eine Ende des Netzteils an den Konverter und das andere Ende an die Stromquelle an. Vergewissern Sie sich dann, dass die Power-LED au euchtet. 0 / 6 0 H Z - 2 4 0 V 5 A C 1 0 0 I N P U T : F U S E :3 .1...
Fehlerbehebung Die Port-LED leuchtet nicht Überprüfen Sie die Kabelverbindung des Konverters. Die Leistung ist schlecht Überprüfen Sie den Geschwindigkeits-Duplex-Modus des Partnergeräts. Der Konverter läuft normalerweise im Autonegotiationsmodus. Wenn der Partner auf Halbduplex eingestellt ist, ist die Leistung schlecht. Die Port-LED leuchtet, aber der Datenverkehr ist unregelmäßig Stellen Sie sicher, dass das angeschlossene Gerät nicht auf dedizierten Vollduplex-Modus eingestellt ist.
Page 25
Kontakt Produktgarantie FS garantiert seinen Kunden, dass wir bei Schäden oder fehlerhaften Artikeln, die auf unsere Verarbeitung zurückzuführen sind, eine kostenlose Rückgabe innerhalb von 30 Tagen nach Erhalt der Ware anbieten. Dies gilt nicht für Sonderanfertigungen oder maßgeschneiderte Lösungen.
Page 26
Nous vous remercions d'avoir choisi ce Convertisseur de Média Ethernet non Géré. Ce guide est conçu pour vous familiariser avec la con guration du convertisseur de média et décrit comment procéder à son déploiement. UMC-GA1SC1T-SM-FX Accessoires Adaptateur d'Alimentation x1 NOTE : L'accessoire peut varier par rapport à...
Présentation du Matériel Ports du Panneau Frontal TP/LNK FX/LNK RJ45 Ports Description RJ45 Port RJ45 10/100/1000Base-T pour connexion Ethernet Port SC pour connexion duplex SC en bre monomode ou multimode LED du Panneau Frontal TP/LNK FX/LNK TP/LNK FX/LNK PWR...
État Description La liaison via le port TP est établie Vert avec succès. TP/LNK Le port TP envoie ou reçoit Vert Clignotant activement des données. Éteint La liaison du port TP est hors service. Vert Le port TP fonctionne à 1000Mbps. Le port TP fonctionne à...
Page 29
Panneau Inférieur (interrupteur DIP) DIP Switch Fonction État Description ÉTEINT Désactivé Fonction LFP ALLUMÉ Activé ÉTEINT Désactivé Fonction ALS ALLUMÉ Activé ÉTEINT Désactivé Réinitialisation FX ALLUMÉ Activé ÉTEINT FX 1000M Réglage de la Vitesse FX ALLUMÉ FX 100M/1000M NOTE : 1.
Conditions d'Installation Ne pas installer l'appareil dans un endroit où la température ambiante est supérieure à 50°C. Le site d'installation doit être bien ventilé. Veillez à ce que le convertisseur soit à niveau et stable a n d'éviter tout risque. Ne pas installer l'appareil dans un environnement poussiéreux.
Page 31
Emplacements pour Mini-convertisseur de Média) 1. Installez les supports de montage sur le côté arrière gauche du convertisseur à l'aide de deux vis. NOTE : Achetez le châssis de mini-convertisseur de média à 12 emplacements MFMC-12DP sur le site fs.com...
Page 32
2. Installez les convertisseurs sur le châssis dans l'ordre (installez d'abord le niveau inférieur, puis le niveau supérieur). Chaque convertisseur peut être xé solidement dans le châssis par deux vis. 3. Placez le châssis dans le rack. Alignez les supports du châssis sur les trous latéraux du rack et xez le châssis au rack à...
Page 33
Connexion du Port RJ45 1. Connectez un câble réseau au port RJ45 du convertisseur. S 3 9 0 0 - 2 4 T 4 S 2. Connectez l'autre extrémité du câble réseau à l'appareil réseau (switch, PC, routeur, etc.).
Connexion du Port SC Connectez une extrémité d'un câble à bre optique au port SC et l'autre extrémité au réseau à bre optique. TX et RX doivent être appariés aux deux extrémités. NOTE : Le convertisseur est installé par défaut avec un émetteur- récepteur à...
Page 35
1. Installation sur Bureau : Connectez une extrémité de l'adaptateur d'alimentation au convertisseur et l'autre extrémité à la source d'alimentation. Véri ez ensuite que l'indicateur lumineux d'alimentation est bien allumé. 0 / 6 0 H Z - 2 4 0 V 5 A C 1 0 0 I N P U T : F U S E :3 .1...
Dépannage L'Indicateur LED du Port n'Est pas Allumé Véri ez la connexion du câble du convertisseur. Les Performances ne Sont pas Bonnes Véri ez la vitesse et le mode duplex de l'appareil connecté. Le convertisseur fonctionne généralement en mode auto- négociation.
Contactez-Nous https://www.fs.com/fr/contact_us.html Garantie du Produit FS garantit à ses clients que tout article endommagé ou défectueux en raison de sa fabrication pourra être retourné gratuitement dans un délai de 30 jours à compter de la date de réception de la marchandise. Cette garantie ne s'applique pas aux articles fabriqués sur mesure ou aux solutions personnalisées.
Page 47
デスクマウントの場合:電源アダプターの一端をコンバーターに 接続し、もう一端を電源に接続します。電源LEDが点灯するかを 確認してください。 0 / 6 0 H Z - 2 4 0 V 5 A C 1 0 0 I N P U T : F U S E :3 .1 F A N O F F ラックマウントの場合:シャーシの電源コードをシャーシに接続 し、シャーシ背面の電源スイッチを入れます。電源LEDが点灯す るかを確認してください。...
