10.3 Composite Video In

Prompter Connector type:
Mating (source) connector:
Pin
Centre
Outer

10.4 Composite input termination

The composite input can be set to high-impedance (for "daisy-chain" operation) or 75 ohm
termination. The input termination is set in the menu – see page xx for more information.

10.5 SD/HD/3G-SDI Prompter and Talent Inputs

The SDI inputs will configure themselves automatically according to the SDI format presented. The
inputs are compliant with SMPTE 259M-C, SMPTE 292M and SMPTE424M standards.
Prompter Connector type:
Mating (cable) connector:

10.6 SD/HD/3G-SDI Auxiliary output

The Auxiliary SDI output is set in the following way (monitor Video Firmware 1.23 or later):
Press and hold the input select button marked "IP", after 5 seconds or so the monitor will
momentarily display "Auxiliary Output", and you should then release the input "IP" button. The
monitor is now ready for you to select the desired video source to be output to the "Switched SDI
Out" connector.
Pressing the IP button scrolls through the four available options as follows:
SW Rev:1.25
75 Ohm BNC Socket
75 Ohm BNC Plug
Description
Composite Video In (PAL, NTSC, or
SECAM)
Ground
75 Ohm BNC Socket
75 Ohm BNC Plug
Pin
Description
Centre
SD/HD-SDI In
Outer
Ground
9
