AO: SFP 1 - This is the SMPTE IP video feed for prompt video (requires SMPTE license and
compatible SMPTE IP SFP device)
AO: SFP 2 - This is the SMPTE IP video feed for talent video and is the default (requires
SMPTE license and compatible 2 channel SMPTE IP SFP device)
AO: SDI P - This is the baseband SDI Prompt input
AO: SDI T - This is the baseband SDI Talent input
Prompter Connector type:
Mating (cable) connector:

10.7 HDMI In

Prompter Connector type: 19 pin HDMI socket: Pin connections are standard HDMI. The input is

10.8 CueLight (Optical) Sensor In

When the CueScript CueLight sensor is installed, it allows the on-board Cue lights to illuminate when
the sensor sees sufficient light. Typically, the sensor is affixed with a Velcro ring around the camera
tally light LED. There are two additional ways the Cue Lights may be triggered:
Ground the sensor input (through a relay or transistor switch).
Apply a voltage (5-24 VDC) to the +Logic Tally input (Tally Sensor In pin 2).
Sensor:
Prompter Connector type:
Mating (cable) connector:
SW Rev:1.25
75 Ohm BNC Socket
75 Ohm BNC Plug
Pin
Description
Centre
SDI Out
Outer
Ground
compatible with HDMI 1.3 / 1.4 / 1.4a.
Photocell device. 16K Ω to 33K Ω @ 10 lux. 1M Ω or more at 0 lux.
Light on the optical sensor or grounded input = CUE LIGHTS ON
No light on the optical sensor or open input = CUE LIGHTS OFF
USB Mini socket
USB Mini plug
10
