10.3 Composite and Component Video In

Prompter Connector type:
Mating (source) connector:
Pin
Center
Outer
NOTE: The video input is terminated in 75 Ohms.

10.4 HD-SDI and SD-SDI Video In and Out

Prompter Connector type:
Mating (source) connector:
Pin
Center
Outer
NOTE: The video input is terminated in 75 Ohms. The output connector provides a re-generated SDI signal.

10.5 VGA In

Description:
Monitor Connector type:
75 Ohm BNC Female Socket
75 Ohm BNC Male Plug
Description
Composite Video In (PAL,NTSC, or SECAM)
Ground
75 Ohm BNC Female Socket
75 Ohm BNC Male Plug
Description
SD or HD SDI
Ground
CueScript CSTM series prompters have a PC compatible VGA input. The
prompter will automatically scale the input resolution to the screen native
resolution.
15 pin High Density D socket
Pin connections are standard VGA.
