12.7

Input select

Cycles through the inputs. Some inputs, especially, take a couple of seconds to lock up to the
incoming signal. This is common with digital signals, especially HDMI.
12.8

Test pattern

Sets prompter to display various test signals (regardless of input setting) for calibration and other set-
up purposes.
12.9

Main H offset

Horizontal picture offset will move the display position horizontally in either direction. The default
value is for nominal centre.
This menu setting is an engineering option and should generally not be used unless directed to do so
by CueScript. Any settings made to this option are not persisted and should they be accidentally
adjusted then power cycling the monitor will restore the correct values.
12.10

Main V offset

Vertical picture offset will move the display position vertically in either direction. The default value is
for nominal centre.
This menu setting is an engineering option and should generally not be used unless directed to do so
by CueScript. Any settings made to this option are not persisted and should they be accidentally
adjusted then power cycling the monitor will restore the correct values.
12.11

Input Enable

Allows for disabling/enabling each video input. Auto Seek function, when enabled, it will cycle
through all enabled video inputs and will lock on first which has signal.
12.12

CueLight Sensor

Sets the sensitivity of the cue light sensor. In high ambient light areas, it may be necessary to reduce
the sensitivity to reduce the risk of false transmission indication.
12.13

Tally switch

Sets the polarity of the logic input pin on the sensor connector
12.14

Flip/mirror

Switches the display in a 4-position cycle (normal/mirror/invert/mirror)
Factory Reset:
Hold this button when powering on the monitor to reset all factory defaults.
12.15

Overscanning

Changes the image size in 5% steps.
SW Rev:1.25
21
