- Page 1 UAT-600-EUR Series Underground Utility Locator UAT-610-EUR UAT-620-EUR User Manual ENG GER ITA SPA FRE DUT POL SWE FIN POR NOR DAN...
-
Page 3: Uat-600-Eur Series Underground Utility Locator
UAT-600-EUR Series Underground Utility Locator UAT-610-EUR UAT-620-EUR User Manual 4/2022, 6011184 C ©2018-2022 Beha-Amprobe All rights reserved. Printed in China... - Page 4 Beha-Amprobe distributor for an exchange for the same or like product. Please check the “Where to Buy” section on beha-amprobe.com for a list of distributors near you. Additionally, in the United States and Canada, in-warranty repair and replacement units can also be sent to an Amprobe Service Center (see address below).
-
Page 5: Table Of Contents
UAT-600-EUR Series Underground Utility Locator CONTENTS 1. PRECAUTIONS AND SAFETY MEASURES ..............2. KIT COMPONENTS ....................... 2.1 Your shipping box includes ....................4 2.2 UAT-600-RE Receiver Controls and Display ................ 5 2.3 UAT-600-RE Receiver Alerts ....................7 2.4 UAT-600-TE Transmitter Controls and Display ..............8 2.5 SC-600-EUR Signal Clamp .................... -
Page 6: Precautions And Safety Measures
CE Declaration of Conformity Hereby, Amprobe declares that the radio equipment contained in this Product is in compliance with Directive 2014/53/EU. The full text of the EU declaration is available at the following internet address:... - Page 7 Warnings: Read Before Using To avoid the possibility of electric shock or personal injury: • Use the Product only as specified in this manual or the protection provided by the instrument may be compromised. • Avoid working alone so assistance can be rendered. •...
-
Page 8: Kit Components
2. KIT COMPONENTS 2.1 Your shipping box includes: UAT-610-EUR UAT-620-EUR UAT-600-RE Receiver UAT-600-TE Transmitter CC-UAT-600-EUR Carrying Case TL-UAT-600 Test Leads Kit* FP-UAT-600 Replacement Fuse User Manual Quick Reference Guide 1.5 V AA (IEC LR6) Batteries (Receiver) 1.5 V D (IEC LR20) Batteries (Transmitter) SC-600-EUR Signal Clamp *TL-UAT-600 Test Leads Kit includes: •... -
Page 9: Uat-600-Re Receiver Controls And Display
2.2 UAT-600-RE Receiver Controls and Display Receiver Controls Light Sensor Speaker LC-Display (high-contrast, sunlight-optimized) Keypad Battery Compartment Power On/Off : press for 2 seconds to turn the Receiver ON/OFF. Volume/Depth • Volume – Press momentarily to change between mute, low, med and hi volume levels. •... - Page 10 Receiver Display The Receiver display features a high-contrast, sunlight-optimized black and white LCD screen. It also has an auto-backlight feature that activates in dark areas for optimized viewing. Speaker Volume Locate Mode Indicator Signal Level – Peak Indicator Signal Level – Number Display (0-999 relates to 0-99.9%) Battery Status Indicator Signal Locating Frequency...
-
Page 11: Uat-600-Re Receiver Alerts
Using the Null Mode To select Null Mode, switch the unit on and press “ENTER” to access the Settings Menu. Select and exit the Settings Menu. The bar graph will now show a minimum signal over the line. The left/right arrows will also indicate the position of the line. 8kHz 8kHz 8kHz... -
Page 12: Uat-600-Te Transmitter Controls And Display
Depth Measurement Related Alerts These alerts are associated with depth measurements and only appear within the depth pop-up screen section. 8kHz 33kHz 50Hz Radio Depth Related Alerts Not possible to compute depth because the signal is too noisy, too weak or too strong. Signal Abnormal Not possible to compute depth because of a strong signal radiating from above (i.e., an overhead cable). - Page 13 Terminals for direct connection and signal clamp Hazardous output voltage indicator. The icon on the screen indicates the transmitter is outputting voltages ≥30 V. Protection fuse Hazardous voltage indicator (over 30 V) The red solid light indicates the presence of AC voltage ≥30 V on the circuit under direct connection mode.
-
Page 14: Sc-600-Eur Signal Clamp
Resistance: This function is only available when test leads are connected to de-energized target line. Refer to the Direct Test Leads Connection Mode section 3.5 to properly connect the test leads. The indicated value is the resistance of the line connected to the Transmitter. -
Page 15: Main Applications
3. MAIN APPLICATIONS Application Receiver setting Transmitter Setting Note Receiver will detect signal Locating energized from any energized 50/60 Hz Power Mode 50/60 Hz cables cable carrying current 50 Hz or 60 Hz carrying current No Transmitter Needed Section 3.2 Receiver will detect Identifying location Radio Mode... -
Page 16: Passive Location Of Energized Cables And Power Lines
If the reading is off scale (too great or too small), then pressing the “ ” buttons together will automatically adjust the sensitivity to bring the meter deflection to 50%. 5. Rotate the Receiver on its axis to obtain the maximum signal. This indicates that the Receiver is directly over the line and aligned with the direction of the cable. -
Page 17: Induction Mode - Locating Utilities
1. Turn the Receiver on by pressing the power button for two seconds. 2. Press the “ ” button repeatedly until Radio is selected. 3. Follow the steps as described in the Receiver Locating section 3.1. The Left/Right arrows are not active during passive location 3.4 Induction Mode –... -
Page 18: Direct Test Leads Connection Mode - Tracing An Individual Pipe Or Cable
3. Press the “ ” buttons to set the output to level one. Increase the level if the resulting signal strength is poor. Increasing the signal unnecessarily may result in the signal being induced into unwanted lines. Induction Mode – Locating with the Receiver 1. - Page 19 IMPORTANT NOTICE, PLEASE READ BEFORE TRACING Avoiding signal cancellation problems with a separate ground connection The signal generated by the Transmitter creates an electromagnetic field around the wire. This field is what is detectable by the Receiver. The clearer this signal, the easier it is to trace the wire. If Transmitter is connected to two adjacent wires on the same circuit (for example, hot and neutral wires on a Romax cable), the signal travels in one direction through the first wire and then returns (in opposite direction) through the second.
- Page 20 Direct Test Leads Connection Mode – Setting Up the Transmitter 1. Turn the Transmitter on by pressing the power button for two seconds. 2. Connect the black and red test leads to the Transmitter inputs. The Transmitter will switch automatically to Direct Connection Mode and the display will show the direct connection icon 3.
-
Page 21: Signal Clamp Accessory - Tracing An Individual Pipe Or Cable
3.6 Signal Clamp Accessory – Tracing an Individual Pipe or Cable In many situations, it is either not possible to gain access to a cable for making an electrical contact or it is not safe to do so. The Signal Clamp provides an efficient and safe method of applying a locate signal to a cable. When using the Signal Clamp, it is best if both ends of the target cable are grounded to enable the current to flow. -
Page 22: Special Applications
4. SPECIAL APPLICATIONS 4.1. When to Use 8 kHz vs. 33 kHz Frequency As a general rule, 8 kHz will provide the best compromise between clarity of signal and effects of “bleed off” to other services. However, there are times when the higher 33 kHz frequency will be beneficial: 1. -
Page 23: Voltage, Resistance And Output Current Measurements Using The Transmitter
The AF-600-EUR A-Frame Ground Fault Locator is an optional accessory specifically designed for the Beha-Amprobe UAT-600-EUR series. In combination with the Transmitter, it will pinpoint the place where a cable metal conductor (either a sheath or a metallic conductor of the wire) touches the ground. It can also detect other conductors to ground faults such as pipeline coating defects. -
Page 24: Maintenance
5. MAINTENANCE 5.1. Battery Replacement Use a flat screw driver to open the battery door. 6 x AA Batteries 8 x D Cell batteries UAT-600-TE UAT-600-RE... -
Page 25: Fuse Replacement
6 x AA Batteries AF-600-EUR 5.2. Fuse Replacement Use a flat screw driver to open the fuse door. Fuse FF 500 mA, 1000 V, IR 30 kA, Φ6.3×32 mm Use only exact fuse replacement. -
Page 26: Specifications
6. SPECIFICATIONS UAT-600-TE Transmitter Operating voltage 0 to 600 V Energized circuit Induction mode: 33 kHz (32,768 Hz) Direct connection modes: 8 kHz (8,192 Hz) and 33 kHz (32,768 Hz) Clamp mode: 8 kHz (8,192Hz) / 33 kHz (32,768Hz) Transmitting frequency De-Energized circuit Induction mode: 33 kHz (32,768 Hz) Direct connection modes: 8 kHz (8,192 Hz), 33 kHz (32,768 Hz), A-Lo/A-Hi... - Page 27 Low battery indication Measurement Category CAT IV 600 V 600 V rms Overload protection Fuse FF 500 mA, 1000 V, IR 30 kA, 6.3×32 mm Agency approval IEC 61010-1, IEC 61010-2-033 Safety compliance CSA/UL 61010-1, CSA/UL 61010-2-033 IEC 61010-031, CSA/UL 61010-031 (test leads) IEC 61326-1 Korea (KCC): Class A Equipment (Industrial Broadcasting &...
- Page 28 Power supply Six (6) 1.5 V AA alkaline batteries 15 minutes idle Auto power off Will auto turn off after 15 min of no button pressing Battery life Approx. 35 hours at 21 °C (70 °F) (Typical) Low battery indication and/or at upper right corner of the screen Measurement Category...
- Page 29 Agency approval IEC 61010-1 Safety compliance CSA/UL 61010-1 IEC 61326-1 Korea (KCC): Class A Equipment (Industrial Broadcasting & Communication Equipment) This product meets requirements for industrial (Class A) electromagnetic Electromagnetic Compatibility wave equipment and the seller or user should take notice of it. This equipment is intended for use in business environments and is not to be used in homes.
- Page 30 TL-UAT-600 Test Lead Set Measurement Category CAT IV 600 V Test leads: 600 V, 10 A max. Operating Voltage and Current Clips : 600 V, 10 A max. Leads length 3.5 m (11.5 ft) Compatible transmitter UAT-600-TE Transmitter Operating temperature and -20 °C to 50 °C (-4 °F to 122 °F), ≤90% RH humidity Storage temperature and...
