- Page 1 AM-60 Compact DMM with NCV & Logic Test Users Manual • Mode d’emploi • Bedienungshandbuch • Manual d’Uso • Manual de uso...
-
Page 3: Compact Dmm With Ncv & Logic Test
AM-60 Compact DMM with NCV & Logic Test Users Manual ©2009 Amprobe Test Tools. All rights reserved. Printed in China... - Page 4 Limited Warranty and Limitation of Liability Your Amprobe product will be free from defects in material and workmanship for 1 year from the date of purchase. This warranty does not cover fuses, disposable batteries or damage from accident, neglect, misuse, alteration, contamination, or abnormal conditions of operation or handling. Resellers are not authorized to extend any other warranty on Amprobe’s behalf.
- Page 5 AM-60 Compact DMM with NCV & Logic Test 3-3/4 digits 2000 counts LCD display Push-buttons for special functions & features Selector to turn the Power On or Off and select Function Input Jack (+) current function Common (Ground reference) Input Jack (-) for all functions...
-
Page 6: Table Of Contents
AM-60 Compact DMM with NCV & Logic Test CONTENTS SYMBOLS .......................2 UNPACKING AND INSPECTION ................3 INTRODUCTION .....................4 OPERATION ......................4 SPECIFICATION ......................8 MAINTENANCE ......................12 TROUBLE SHOOTING .....................12 Fuse Replacement ....................13 Battery Replacement ..................13... -
Page 7: Symbols
SYMBOLS Warning! Dangerous Voltage (Risk of electric shock). � Caution ! Refer to the user’s manual before using this Meter. Double Insulation or Reinforced insulation Alternating Current (AC). Direct Current (DC). Low battery indicator Fuse Ground (maximum permitted voltage between terminal and ground). -
Page 8: Unpacking And Inspection
UNPACKING AND INSPECTION Your shipping carton should include: AM-60 Meter Test Leads Battery (SIZE AAA, 1.5V) User’s Manual If any of the items are damaged or missing, return the complete package to... -
Page 9: Introduction
INTRODUCTION Multimeter AM-60 can be used to measure voltage, resistance, capacitance, frequency, current; It is an electronic measuring instrument that combines several measurement functions in one unit. AM-60 multimeter is portable hand-held devices useful for basic fault finding and field service work or a bench instrument which can measure to a very high degree of accuracy. - Page 10 Resistance and Capacitance Note – To improve the measurement accuracy of small value capacitor, record the reading with the test leads open then substract the residual capacitance of the Meter and leads from measurement. UNKNOWN MEASUREMENT RESIDUAL MIN MAX Record Measuring DC / AC Current...
- Page 11 Display Hold Manual Ranging and Auto Ranging Auto Power Off (Battery Saver)
- Page 12 Disable Auto Power Off Non-Contact Voltage (Volt sense) 1. Volt sense switch will be activated on any function or at OFF status. 2. Test leads are not used for the Volt sense test. 3. Press the Volt sense button. The display goes black, a tone sounds and the red LED lights up to verify the instrument is operational.
-
Page 13: Specification
SPECIFICATIONS General Specifications Display : 2000 counts. Polarity Indication : Automatic, positive implied, negative indicated. Overrange Indication : “OL” or “-OL”. Batteries Life : Alkaline 250 hours Low Batteries Indication : “N” is displayed when the batteries voltage drops below operating voltage. Auto Power Off : Approx 10 minutes. - Page 14 DC / AC Volts Range AC Accuracy 200.0mV * Unspecified 2.000V * ±(1.5%+5dgt) 50Hz ~ 300Hz 20.00V ~ 200.0V * ±(1.5%+5dgt) 50Hz ~ 500Hz 750V AC / 1000V DC DC Accuracy : ±(0.5% + 2dgt) Over voltage protection : 1000V DC or 750 V ACrms. Input Impedance : 10Me // less than 100pF.
- Page 15 * AC Conversion Type : Conversion type and additional specification are same as DC/AC Voltage. ** Ampere Testing Duty Ratio Table Ampere Testing Time Rest Time 1min 10min 2min 10min 3min 10min 4min 10min 5min 10min Continually Resistance Range Accuracy Voltage Burden 200.0~200.0Ke ** ±(0.7% + 3 dgt)
- Page 16 Frequency Range Sensitivity Accuracy >1.5 Vac rms, 2000Hz ~ 200.0KHz <5 Vac rms Frequency : 0.01%±1digit >2 Vac rms, 2.000MHz ~ 20.00MHz <5 Vac rms Overload Protection : 600V rms. Minimum pulse width : >25 ns Duty cycle limits : >30% and <70% Capacitance Overload Range...
-
Page 17: Maintenance
MAINTENACE If there appears to be a malfunction during the operation of the meter, the following steps should be performed in order to isolate the cause of the problem. 1. Check the battery. Replace the battery immediately when the “N” symbol appears on the LCD. -
Page 18: Fuse Replacement
Fuse Replacement Refer to the following figure to replace fuse : CAUTION: • Use only a fuse with the amperage, interrupt, voltage, and speed rating specified. • Fuse rating : 10A, 500V Battery Replacement Refer to the following figure to replace the batteries:...
