CAT 5000 WiFi Retro Fit Kit
Wireless Retrofit for CAT 5000 Water Quality Controllers
IMPORTANT SAFETY INSTRUCTIONS
Basic safety precautions should always be followed, including the following: Failure to fol-
low instructions can cause severe injury and/or death.
This is the safety-alert symbol. When you see this symbol on your equipment or in this
manual, look for one of the following signal words and be alert to the potential for personal
injury.
WARNING warns about hazards that could cause serious personal injury, death or ma-
jor property damage and if ignored presents a potential hazard.
CAUTION warns about hazards that will or can cause minor or moderate personal injury
and/or property damage and if ignored presents a potential hazard. It can also make con-
sumers aware of actions that are unpredictable and unsafe.
Owner's Manual
RFK-C5000-WIFI
Hayward Commercial Pool Products
10101 Molecular Drive, Suite 200
Rockville, MD 20850
www.haywardcommercialpool.com
USE ONLY HAYWARD GENUINE REPLACEMENT PARTS
Contents
Introduction.........................2
Before you Begin..................2
Installation...........................3
Activation.........................9
Returning Original Parts.......13
092518 RevC
Advertisement
Related Manuals for Hayward CAT 5000
Summary of Contents for Hayward CAT 5000
-
Page 1: Table Of Contents
092518 RevC CAT 5000 WiFi Retro Fit Kit Wireless Retrofit for CAT 5000 Water Quality Controllers Owner’s Manual Contents Introduction......2 Before you Begin....2 Installation......3 Activation......9 Returning Original Parts..13 RFK-C5000-WIFI IMPORTANT SAFETY INSTRUCTIONS Basic safety precautions should always be followed, including the following: Failure to fol- low instructions can cause severe injury and/or death. -
Page 2: Introduction
Introduction The RFK-C5000-WIFI is a retrofit kit used to replace the pager communication components in the CAT 5000 Controller with WiFi components. The RFK-C5000-WIFI uses WiFi/Internet communication to connect with the PoolCom. Before You Begin Write down the following information BEFORE installing the retrofit kit. The numbers below are necessary for activation and will not be accessible after the retrofit kit is installed. -
Page 3: Installation
Unplug the ribbon cable where shown, and set aside. 2) Remove (4) screws holding the “Riser Board Assembly” (Display screen). Be sure to remove the screws on the larger board, NOT the smaller one. USE ONLY HAYWARD GENUINE REPLACEMENT PARTS... - Page 4 6) NOTE: BEFORE PULLING BOTH CHIPS, NOTE TEXT ORI- ENTATION ON EACH CHIP. (One chip shown removed). Using the chip puller supplied, remove old processor chips. (These must also be return-shipped to Hayward in supplied anti-static case). 8) Carefully remove the red backing from the 7) Place old chips in the anti-static case provided for shipment.
- Page 5 13) On ONE screw only, cut off one edge of screw head 14) Insert cut screw through transceiver board, spacer as shown. This prevents interference with antenna and motherboard as shown. cable socket when assembled. USE ONLY HAYWARD GENUINE REPLACEMENT PARTS...
- Page 6 18) Apply ribbon cable to motherboard. Note orientation of shown. red wire and notch/tab in connector. 19) Insert cable antenna through hole in bottom of housing. 20) Install lock washer and nut and tighten with pliers. USE ONLY HAYWARD GENUINE REPLACEMENT PARTS...
- Page 7 24) Motherboard assembly with adhesive feet, ready for installation. 26) Attach antenna cable to transceiver by pushing cable 25) Adhere the motherboard assembly to the inside of connector onto pc board socket where shown. the enclosure. USE ONLY HAYWARD GENUINE REPLACEMENT PARTS...
- Page 8 28) Thread nut on to antenna cable completely. Then insert 27) Approximate location shown here. cable fitting through mounting hole. 29) Re-fasten with (4) screws. 30) Plug in faceplate ribbon cable. 31) Re-attach faceplate. USE ONLY HAYWARD GENUINE REPLACEMENT PARTS...
-
Page 9: Activation
Activation After installing the RFK-C5000-WIFI retrofit kit, contact Hayward for activation. Activation Phone Number: 301-838-4001 Be prepared to provide the following information: Name Company Name Contact Information Facility Name Cat Serial Number Wifi Transceiver Serial Number (refer to page 1) - Page 10 WiFi Connectivity Checklist Specific information about your wireless network is required to configure the CAT 5000 Controller for wireless operation. To aid in installation, fill out the information below and then proceed to the following steps. Wireless Network ID/Name __________________ Network Security Type (Check one of the following)* a.
- Page 11 4) Press ENTER under the “Network” selection. 5) Scroll down to find your wireless network. Press ENTER to select. If display shows “None”, then please allow an additional 5 minutes for unit to try to find networks. USE ONLY HAYWARD GENUINE REPLACEMENT PARTS...
- Page 12 9) Using the UP and DOWN buttons, input the pass- word to your router, then press ENTER. Allow at least 5 minutes for unit to establish network connection, depending on your wireless network speed. USE ONLY HAYWARD GENUINE REPLACEMENT PARTS...
-
Page 13: Returning Original Parts
Pack the original Microprocessor chip in the provided anti-static box and the original Transceiver in the provided anti-static bag and ship to: Hayward Industries Attn: Patti Eads 61 Whitecap Drive N. Kingstown, RI 02852 Note: Parts must be returned with in 30 days to receive $100.00 credit. USE ONLY HAYWARD GENUINE REPLACEMENT PARTS... - Page 14 USE ONLY HAYWARD GENUINE REPLACEMENT PARTS...
- Page 15 USE ONLY HAYWARD GENUINE REPLACEMENT PARTS...
- Page 16 Hayward, CAT Controllers and CAT 1000 are registered trademarks of Hayward Industries, Inc. © 2012 Hayward Industries, Inc. All other trademarks not owned by Hayward are the property of their respective owners. Hayward is not in any way affiliated with or endorsed by those third parties.
