092432 RevE
CAT 5000
®
Water Quality Controller
Owner's Manual
\
Contents
Introduction............................................2
Installation..............................................4
Pool Chemistry .......................................7
Configuration..........................................7
System Maintenance.............................27
Network Communications.....................28
Troubleshooting....................................32
Warranty...............................................38
CAT-5000
Hayward Pool Products
620 Division Street, Elizabeth NJ 07207
www.hayward.com
USE ONLY HAYWARD GENUINE REPLACEMENT PARTS

Advertisement

loading
Need help?

Need help?

Do you have a question about the CAT 5000 and is the answer not in the manual?

Questions and answers

Related Manuals for Hayward CAT 5000

Summary of Contents for Hayward CAT 5000

  • Page 1: Table Of Contents

    092432 RevE CAT 5000 ® Water Quality Controller Owner’s Manual Contents Introduction..........2 Installation..........4 Pool Chemistry ........7 Configuration..........7 System Maintenance......27 Network Communications.....28 Troubleshooting........32 Warranty..........38 CAT-5000 Hayward Pool Products 620 Division Street, Elizabeth NJ 07207 www.hayward.com USE ONLY HAYWARD GENUINE REPLACEMENT PARTS...
  • Page 2 CAT Controllers recommends always having the “Overfeed Timeout” functions enabled as a precautionary measure. By disabling the “Overfeed Timeout” the overfeeding of chemi- cals could occur and create unsafe water chemistry conditions. Overfeeding chemicals is dangerous and could potentially harm patrons. SAVE THESE INSTRUCTIONS USE ONLY HAYWARD GENUINE REPLACEMENT PARTS...

  • Page 3: Introduction

    The results include elimination of “human error”, accurate and reliable maintenance of chemical levels twenty-four hours a day, compliance with Health Department operating standards, reduced burden on operating staff, and a reduction of chemical usage and costs. The CAT 5000 control- ler and POOLCOMM water quality management website together provide unprecedented control, access and documentation.
  • Page 4 The ideal pH range for pools and spas is 7.4 - 7.6. The CAT 5000 controller is preset from the factory to maintain pH 7.5. If pH is maintained below 7.4 (too acidic), eye irritation, corrosion of equipment, and damage to the pool or spa surface can occur.

  • Page 5: Installation

    30’ Roll, Blue Poly Installation Tubing (3/8” OD) 1/4” NPT x 3/8” Tubing True-Seal Connectors CAT 5000 Quick Reference Guide NOTE: Before commencing installation, please confirm that items listed above have been included. Please report any shortages immediately to the factory.
  • Page 6 Mark tubing bottoms out and on tubing to release. 3/4” from end. This insertion mark is no Repeat steps 1 and 2 is the insertion mark. longer visible. to reuse fitting. O-Ring Tubing USE ONLY HAYWARD GENUINE REPLACEMENT PARTS...
  • Page 7 Typical Cat 5000 Installation Diagram: USE ONLY HAYWARD GENUINE REPLACEMENT PARTS...

  • Page 8: Pool Chemistry

    Confirm that your pool or spa water conforms to the following ranges before powering on and setting up the CAT 5000. The table below indicates generally accepted guidelines. Always maintain water chemistry accord- ing to standards set by your local or State Health Department.
  • Page 9 To Change The Brightness Of The Display: The display intensity can be changed to accommodate comfortable viewing in a variety of lighting circumstances. While in normal operating mode: Press UP to increase display intensity. Press DOWN to decrease display intensity. USE ONLY HAYWARD GENUINE REPLACEMENT PARTS...
  • Page 10 Setpoint To Change The pH Setpoint: The CAT 5000 is programmed at the factory with a default setpoint of pH 7.5. CAT Controllers considers this to be ideal for pool and spa applications. The following steps enable the selection of a different setpoint.
  • Page 11 To Change The ORP Setpoint: The CAT 5000 is programmed at the factory to maintain ORP at 650 mV by default. This is the generally accepted world standard for safe drinking water. In order to maintain a given chlorine or...
  • Page 12 To Select ORP Feed Mode: The CAT 5000 is programmed at the factory to operate in automatic feed mode as the default set- ting. Other ORP feed mode selections include off (disabled), and manual on for a fixed interval up to 25 minutes after which automatic feed will resume.
  • Page 13 To Change The pH Control Mode: The CAT 5000 is programmed at the factory to operate in the acid feed mode by default (when pH exceeds setpoint, the pH chemical feeder is activated). If the sanitizer or other factors of the application cause the pH to decrease, base feed mode must be selected.
  • Page 14 Press ENTER to save your selection. pH Feed: The CAT 5000 by default uses a time-based proportional feed algorithm which enables the control of virtually any body of water without under-feeding or overshooting the setpoint. With some types of chemical feeders, however, it is beneficial to disable proportional feed and feed on a fixed basis.
  • Page 15 Controllers recommends always having the “Overfeed Timeout” functions enabled as a precaution- ary measure. By disabling the “Overfeed Timeout” the overfeeding of chemicals could occur and create unsafe water chemistry conditions. Overfeeding chemicals is dangerous and could poten- tially harm patrons. USE ONLY HAYWARD GENUINE REPLACEMENT PARTS...
  • Page 16 ORP Feed: The CAT 5000 by default uses a time-based proportional feed algorithm which enables the precise control of virtually any body of water. With some types of chemical feeders, however, it is benefi- cial to disable proportional feed and dispense chemicals on a fixed basis. From the Configuration Setup Menu: Press DOWN to find the ORP Feed menu item.
  • Page 17 Press ENTER to select ORP High Alarm. The current ORP High Alarm Setting will be displayed: ORP High Alarm 900 mV Press UP or DOWN to scroll to the desired setting. Press ENTER to save your selection. USE ONLY HAYWARD GENUINE REPLACEMENT PARTS...
  • Page 18 Press ENTER to select Auxiliary pH Setpoint. The current Auxiliary pH Setpoint will be displayed: AUX pH Setpoint 7.5 pH Press UP or DOWN to scroll to the desired setting. Press ENTER to save your selection. USE ONLY HAYWARD GENUINE REPLACEMENT PARTS...
  • Page 19 Press ENTER to select Feed On Alarm. The current Feed On Alarm setting will be displayed: Feed on Alarm Press UP or Down to scroll to desired setting. Press ENTER to save your selection. USE ONLY HAYWARD GENUINE REPLACEMENT PARTS...
  • Page 20 Press DOWN to view the following options: Disabled Digital Flow (ENTER to select pipe size). Level Sensor Press ENTER to confirm the selection. After 10 seconds, the controller will revert to the Configuration Setup Menu. USE ONLY HAYWARD GENUINE REPLACEMENT PARTS...
  • Page 21 Press ENTER to select Digital Flow Sensor Type. The current Digital Flow Sensor Type setting will be displayed: Digital Flow Sensor Type Blue-White Press UP or Down to scroll to desired setting. Press ENTER to save your selection. USE ONLY HAYWARD GENUINE REPLACEMENT PARTS...
  • Page 22 Press ENTER to select Temperature Low Alarm. The current Temperature Low Alarm setting will be displayed: Temperature Low Alarm 20*F Press UP or Down to scroll to desired setting. Press ENTER to save your selection. USE ONLY HAYWARD GENUINE REPLACEMENT PARTS...
  • Page 23 After 10 seconds, the controller will revert to the Configuration Setup Menu. Update FW via BL: This feature is used to update firmware on the controller. Please contact Hayward Commercial at 301-838-4001 if you have firmware issues with your controller. From the Configuration Setup Menu: Press DOWN to find the Update FW via BL Menu item.
  • Page 24 Demonstration Mode: The Demo Mode enables the CAT 5000 to be used as a demonstration, training, or sales aid. All functions, menus, and settings of the controller are active except that pH is simulated at 7.5 and ORP is simulated at 650 mV.
  • Page 25 Caution: Demonstration Mode must never be used when the CAT 5000 is connected to active chemical feeders or otherwise in use as a water quality controller. The CAT 5000 is simulating pH and ORP values, and therefore is not sampling the sensors or monitoring water quality.
  • Page 26 Off, 5 to 240 Minutes (Default 240 Min.) AUX pH Setpoint 0.0 to 14.0 (Default 7.5 pH) 400 to 995 mV (Default 650 mV) AUX ORP Setpoint Alarm Setup Audible and Visual Visual Only Feed on Alarm USE ONLY HAYWARD GENUINE REPLACEMENT PARTS...
  • Page 27 Temperature Format Fahrenheit or Celsius Temp Setpoint 32 to 104ºF, or 0 to 40ºC Temp. Low Alarm 32 to 104ºF, or 0 to 40ºC Temp. High Alarm 32 to 104ºF, or 0 to 40ºC USE ONLY HAYWARD GENUINE REPLACEMENT PARTS...

  • Page 28: System Maintenance

    System Maintenance Cat 5000 Controller Package The CAT 5000 controller unit is virtually maintenance free. Cleaning of the enclosure, front panel and flow cell can be performed using a clean, soft cloth moistened with mild soap and water solution or glass cleaner. Use of abrasives or harsh chemicals may damage the enclosure and membrane switch panel.

  • Page 29: Network Communications

    Winterization The sensors should be prepared for storage as outlined above and protected from freezing tem- peratures. Although the CAT 5000 controller is designed to withstand a broad temperature range, winter storage in a secure location may be desirable. The flow cell and poly tubing must be drained prior to exposure to freezing temperatures. Either purge all water using compressed air or thoroughly drain through the valve ports and tubing con- nections.
  • Page 30 Test w/ a CAT 5000 The best way to check for coverage at a facility is to test with an actual CAT 5000. The Transmit data button has been provided specifically for this purpose. Place the CAT 5000 unit where you expect to install it and press the transmit data button.
  • Page 31 Red: A warning condition currently exists. Facility Name This field provides a list of facilities automated with CAT 5000 wireless controllers. Click on a facil- ity name to enter the Unit Profile for the controller. From the Unit Profile, the following settings can be modified online: Facility name, location and time zone information.
  • Page 32 To update the website with the latest data from the CAT 5000, click the Get Data link at the bottom of the page. The following screen capture shows the settings which can be modified from the Unit Profile screen: Site Location This field is used to identify the specific asset being monitored (main pool, lap pool, spa, etc.)

  • Page 33: Troubleshooting

    Overfeed The pH Overfeed timeout occurs when the CAT 5000 has been feeding chemicals for a time greater than the selected maximum feed time and has not reached its setpoint. A properly selected Overfeed timeout prevents the unit from continuing to feed chemicals when the chemical supply has been diminished or a chemical feeder has become clogged or broken.
  • Page 34 Key Inserted When a service technician visits the CAT 5000 he may insert a service key (optional), which will be logged by the controller to document the time and duration of his visit.
  • Page 35 ORP Low and High Alarms pH Priority Feed pH Overfeed Timeout ORP Overfeed Timeout Supplemental Feed Modes Optional Equipment Optical Level Sensors Digital Flow Rate Sensor Rotary Flow Sensor Remote Dome Antenna Sensor Output Signal Requirements 0-14 pH, 0-1000mV ORP USE ONLY HAYWARD GENUINE REPLACEMENT PARTS...
  • Page 36 Addendum for UL Listed Models CAT 5000 - Revision I Terminal Block Wiring Instructions The CAT 5000 UL listed controller must be installed in conformance with local and national electri- cal codes using hard-wired electrical connections. Please refer to the instructions below: Disconnect power at circuit breaker.
  • Page 37 USE ONLY HAYWARD GENUINE REPLACEMENT PARTS...
  • Page 38 USE ONLY HAYWARD GENUINE REPLACEMENT PARTS...

  • Page 39: Warranty

    WARRANTY Hayward warrants the CAT 5000 automated controller to be free of defects ® in material and workmanship for a period of five years from date of ship- ment from our factory or authorized distributor. Liability under this warranty is limited to the repair or replacement of any device or component which is returned to the factory within five years of delivery to original purchaser, shipping prepaid, and which is found to be defective upon examination.
  • Page 40 CONTENTS COPYRIGHT 2015 HAYWARD INDUSTRIES, INC. ALL RIGHTS RESERVED All other trademarks not owned by Hayward are the property of their respective owners. Hayward is not in any way affiliated with or endorsed by those third parties. USE ONLY HAYWARD GENUINE REPLACEMENT PARTS...
