Hayward CAT 5500 Owner's Manual

Water quality controller
Hide thumbs

Advertisement

Quick Links

Download this manual
092601 RevB
CAT 5500
®
Water Quality Controller
Owner's Manual
\
Contents
Introduction.......................................2
Installation........................................4
Pool Chemistry ..................................7
Configuration.....................................7
System Maintenance........................24
Network Communications................25
Troubleshooting...............................29
Warranty..........................................34
CAT-5500
Hayward Pool Products
620 Division Street, Elizabeth NJ 07207
www.hayward.com
USE ONLY HAYWARD GENUINE REPLACEMENT PARTS

Advertisement

loading

Related Manuals for Hayward CAT 5500

Summary of Contents for Hayward CAT 5500

  • Page 1: Table Of Contents

    092601 RevB CAT 5500 ® Water Quality Controller Owner’s Manual Contents Introduction........2 Installation........4 Pool Chemistry ........7 Configuration........7 System Maintenance......24 Network Communications....25 Troubleshooting.......29 Warranty..........34 CAT-5500 Hayward Pool Products 620 Division Street, Elizabeth NJ 07207 www.hayward.com USE ONLY HAYWARD GENUINE REPLACEMENT PARTS...
  • Page 2 By disabling the “Overfeed Timeout” the overfeeding of chemicals could occur and create unsafe water chemistry conditions. Overfeeding chemicals is dangerous and could potentially harm patrons. Certification - NSF 50 Certified for ph/ORP Display and Output only SAVE THESE INSTRUCTIONS USE ONLY HAYWARD GENUINE REPLACEMENT PARTS...

  • Page 3: Introduction

    The results include elimination of “human error”, accurate and reliable maintenance of chemical levels twenty-four hours a day, compliance with Health Department operating standards, reduced burden on operating staff, and a reduction of chemical usage and costs. The CAT 5500 control- ler and POOLCOMM water quality management website together provide unprecedented control, access and documentation.
  • Page 4 The ideal pH range for pools and spas is 7.4 - 7.6. The CAT 5500 controller is preset from the factory to maintain pH 7.5. If pH is maintained below 7.4 (too acidic), eye irritation, corrosion of equipment, and damage to the pool or spa surface can occur.

  • Page 5: Installation

    Drill and tap a 1/4” NPT port at a location subject to vacuum or reduced pressure. Install the remaining tubing connector and run flex tubing to the effluent flow cell port. USE ONLY HAYWARD GENUINE REPLACEMENT PARTS...
  • Page 6 Mark tubing bottoms out and on tubing to release. 3/4” from end. This insertion mark is no Repeat steps 1 and 2 is the insertion mark. longer visible. to reuse fitting. O-Ring Tubing USE ONLY HAYWARD GENUINE REPLACEMENT PARTS...
  • Page 7 Typical Cat 5500 Installation Diagram USE ONLY HAYWARD GENUINE REPLACEMENT PARTS...

  • Page 8: Pool Chemistry

    Confirm that your pool or spa water conforms to the following ranges before powering on and setting up the CAT 5500. The table below indicates generally accepted guidelines. Always maintain water chemistry accord- ing to standards set by your local or State Health Department.
  • Page 9 To Change The Brightness Of The Display: The display intensity can be changed to accommodate comfortable viewing in a variety of lighting circumstances. While in normal operating mode: Press UP to increase display intensity. Press DOWN to decrease display intensity. USE ONLY HAYWARD GENUINE REPLACEMENT PARTS...
  • Page 10 Setpoint To Change The pH Setpoint: The CAT 5500 is programmed at the factory with a default setpoint of pH 7.5. CAT Controllers considers this to be ideal for pool and spa applications. The following steps enable the selection of a different setpoint.
  • Page 11 To Change The ORP Setpoint: The CAT 5500 is programmed at the factory to maintain ORP at 650 mV by default. This is the generally accepted world standard for safe drinking water. In order to maintain a given chlorine or...
  • Page 12 To Select ORP Feed Mode: The CAT 5500 is programmed at the factory to operate in automatic feed mode as the default set- ting. Other ORP feed mode selections include off (disabled), and manual on for a fixed interval up to 25 minutes after which automatic feed will resume.
  • Page 13 To Change The pH Control Mode: The CAT 5500 is programmed at the factory to operate in the acid feed mode by default (when pH exceeds setpoint, the pH chemical feeder is activated). If the sanitizer or other factors of the application cause the pH to decrease, base feed mode must be selected.
  • Page 14 Feed: The CAT 5500 by default uses a time-based proportional feed algorithm which enables the control of virtually any body of water without under-feeding or overshooting the setpoint. With some types of chemical feeders, however, it is beneficial to disable proportional feed and feed on a fixed basis.
  • Page 15 ORP Feed: The CAT 5500 by default uses a time-based proportional feed algorithm which enables the precise control of virtually any body of water. With some types of chemical feeders, however, it is benefi- cial to disable proportional feed and dispense chemicals on a fixed basis. From the Configuration Setup Menu: Press DOWN to find the ORP Feed menu item.
  • Page 16 Controllers recommends always having the “Overfeed Timeout” functions enabled as a precaution- ary measure. By disabling the “Overfeed Timeout” the overfeeding of chemicals could occur and create unsafe water chemistry conditions. Overfeeding chemicals is dangerous and could poten- tially harm patrons. USE ONLY HAYWARD GENUINE REPLACEMENT PARTS...
  • Page 17 The current Salt High Alarm setting will be displayed: Salt High Alarm 5500 ppm Press UP or Down to scroll to desired setting. Press ENTER to save your selection. Press MENU to return to Operating Menu. USE ONLY HAYWARD GENUINE REPLACEMENT PARTS...
  • Page 18 Press ENTER to select Alarm Setup. The current Alarm Setup option will be displayed: Alarm Setup Audible and Visual Press UP or DOWN to scroll to the desired setting. Press ENTER to save your selection USE ONLY HAYWARD GENUINE REPLACEMENT PARTS...
  • Page 19 The default value is 2.14%. From the Configu- ration Setup Menu: Press DOWN to find the Temp. Compensation Menu item. Press ENTER to select Temp. Compensation. The current Temp. Compensation setting will be displayed: USE ONLY HAYWARD GENUINE REPLACEMENT PARTS...
  • Page 20 Used to calibrate Salinity Factor to manual test readings. The default value is 0.98. The TDS Offset calibration must be completed prior to adjusting this setting. Please than adjust the displayed value up or down until it matches the accurate manually tested reference reading. From the Configura- tion Setup Menu: USE ONLY HAYWARD GENUINE REPLACEMENT PARTS...
  • Page 21 Press DOWN to find the Hard Reset menu item. Press ENTER to select Hard Reset. Press ENTER at the prompt to confirm the selection. The CAT 5500 will reset and perform a diagnostic self-test: Diagnostic Self Check After 10 seconds, the controller will revert to the Configuration Setup Menu.
  • Page 22 Update FW via BL Demonstration Mode: The Demo Mode enables the CAT 5500 to be used as a demonstration, training, or sales aid. All functions, menus, and settings of the controller are active except that pH is simulated at 7.5 and ORP is simulated at 650 mV.
  • Page 23 Off, 5 to 120 Minutes (Default 120 Min.) AUX pH Setpoint 0.0 to 14.0 (Default 7.5 pH) 400 to 995 mV (Default 650 mV) AUX ORP Setpoint Alarm Setup Audible and Visual Visual Only USE ONLY HAYWARD GENUINE REPLACEMENT PARTS...
  • Page 24 50mm to 315mm Digital Flow Pipe Size Digital Flow Alarm Select Alarm Flow Rate Display System Information ENTER to Display Hard Reset ENTER to Reset Restore Factory Defaults ENTER to Restore Demonstration Mode Off, USE ONLY HAYWARD GENUINE REPLACEMENT PARTS...

  • Page 25: System Maintenance

    System Maintenance Cat 5500 Controller Package The CAT 5500 controller unit is virtually maintenance free. Cleaning of the enclosure, front panel and flow cell can be performed using a clean, soft cloth moistened with mild soap and water solution or glass cleaner. Use of abrasives or harsh chemicals may damage the enclosure and membrane switch panel.

  • Page 26: Network Communications

    Test w/ a CAT 5500 The best way to check for Reflex coverage at a facility is to test with an actual CAT 5500. The Transmit data button has been provided specifically for this purpose. Place the CAT 5500 unit where you expect to install it and press the transmit data button.
  • Page 27 If you find your client location does not have Skytel coverage contact the POOLCOMM Program Manager for secondary carrier availability. Activating Communications To activate your first CAT 5500 wireless controller on the POOLCOMM web site you must first register an account. Call 800-657-2287 and ask for the POOLCOMM Program Administrator if you need assistance.
  • Page 28 Red: A warning condition currently exists. Facility Name This field provides a list of facilities automated with CAT 5500 wireless controllers. Click on a facil- ity name to enter the Unit Profile for the controller. From the Unit Profile, the following settings can be modified online: Facility name, location and time zone information.
  • Page 29 To update the website with the latest data from the CAT 5500, click the Get Data link at the bottom of the page. The following screen capture shows the settings which can be modified from the Unit Profile screen: Site Location This field is used to identify the specific asset being monitored (main pool, lap pool, spa, etc.)

  • Page 30: Troubleshooting

    The POOLCOMM website can provide email alerts through every major cell phone provider. You can set up your Poolcomm account to alert you with a text message any time an alarm is activated at one of your CAT 5500 locations. Just follow each company’s e-mail to text message instructions. AT&T Your cell phone’s e-mail address: 10-digit cell phone number@mobile.att.net Motorola’s MX2000...
  • Page 31 No Flow The CAT 5500 is equipped with a flow sensor to prevent the controller from feeding chemicals in the absence of proper recirculation. First check the filtration system to ensure that it is running and that water is moving through the flow cell. If water is flowing and the alarm is still sounding check flow sensor for obstruction.
  • Page 32 Key Inserted When a service technician visits the CAT 5500 he may insert a service key (optional), which will be logged by the controller to document the time and duration of his visit.
  • Page 33 ORP Low and High Alarms pH Priority Feed pH Overfeed Timeout ORP Overfeed Timeout Supplemental Feed Modes Optional Equipment Optical Level Sensors Digital Flow Rate Sensor Rotary Flow Sensor Remote Dome Antenna Sensor Output Signal Requirements 0-14 pH, 0-1000mV ORP USE ONLY HAYWARD GENUINE REPLACEMENT PARTS...
  • Page 34 Addendum for UL Listed Models CAT 5500 - Revision I Terminal Block Wiring Instructions The CAT 5500 UL listed controller must be installed in conformance with local and national electri- cal codes using hard-wired electrical connections. Please refer to the instructions below: Disconnect power at circuit breaker.

  • Page 35: Warranty

    WARRANTY Hayward warrants the CAT 5500 automated controller to be free of defects ® in material and workmanship for a period of five years from date of ship- ment from our factory or authorized distributor. Liability under this warranty is limited to the repair or replacement of any device or component which is returned to the factory within five years of delivery to original purchaser, shipping prepaid, and which is found to be defective upon examination.
  • Page 36 CONTENTS COPYRIGHT 2015 HAYWARD INDUSTRIES, INC. ALL RIGHTS RESERVED All other trademarks not owned by Hayward are the property of their respective owners. Hayward is not in any way affiliated with or endorsed by those third parties. USE ONLY HAYWARD GENUINE REPLACEMENT PARTS...
