Fransgard DM-3250 Manual

Disc mower
Hide thumbs

Advertisement

Quick Links

Download this manual
Manual
GB
DM-3250
Disc mower
Ab serial # :
57550001 →

Advertisement

loading
Need help?

Need help?

Do you have a question about the DM-3250 and is the answer not in the manual?

Questions and answers

Related Manuals for Fransgard DM-3250

Summary of Contents for Fransgard DM-3250

  • Page 1 Manual DM-3250 Disc mower Ab serial # : 57550001 →...
  • Page 2 Fransgård Maskinfabrik A/S Fredbjergvej 132 DK - 9640 Farsø Telefon: +45 98 63 21 22 www.fransgard.dk mail@fransgard.dk...

  • Page 3: Table Of Contents

    Ordering spare parts ..............4 Lubrication and Maintenance ............4 Transport chain ................5 Mounting of Disc with hat ............... 6 Mounting / assembling instruction ..see www.fransgard.dk TECHNICAL SPECIFICATIONS Working width ............... 3,20m. Transport width .............. 1,90m/6'3". Working speed, max........6-15km/h 3,5-9 mph.

  • Page 4: Safety Precautions

    SAFETY PRECAUTIONS All screens must be correctly positioned and checked before starting the machine. Take care for stone fling. It is not advisable to remain in the working area of the machine while working parts are rotating. The machine is made to work in grass and straw crops and must not be used for anything else.

  • Page 5: Working Position

    WORKING POSITION Dismount the safety chain and release the transport lock (A). Lover the cutter bar until there is about 20mm. in free of the slide (B) see the illustration. Adjust the tractor´s depth stop, if the tractor´s depth stop is in bad condition, then use enclosed bracket, and tighten the safety chain into the top bar bracket on the tractor, so the machine can be kept in place.

  • Page 6: Lubrication And Maintenance

    LUBRICATION AND MAINTENANCE Lubricate PTO shaft after every 10 hours of operation and lubricate the indicated lubrication points as and when required. Retighten bolts. Correct tighten of knife bolt – 100 N Correct tighten of disc bolt - 170 N Check the V-belts before every start, when the V-belts is proper tightened it can be pushed approx.

  • Page 7: Transport Chain

    Transport chain for K & DM- disc mower, And chain for less pressure on the lift arms...

  • Page 8: Mounting Of Disc With Hat

    Mounting of Disc with hat. Remove the nut, small disc and protection bushing from the shaft. Mount the Disc with hat, as shown on the picture, with the small disc and nut. Mount the plastic cover on the top. (You shall not use the protection bushing)
