Page 3
LIST OF CONTENTS Page Technical specifications............1 Regulation ................2 Mounting ................2 Safety Precautions ..............2 Assembly instructions ............2 Working position ..............3 Overload release ..............3 Transport position ..............3 Lubrication and maintenance ..........4 Changing chain ..............4 Ordering spare parts ..............
Page 4
There should only be used original Fransgard spare parts. ASSEMBLE INSTRUCTIONS.
Page 5
WORKING POSITION. The machine can work out the side in a horizontal position, with a slope of about 35 ° and can work up to approximately vertical. 90 °. The machine must only be launched when the flail head is in its lowered position. To achieve the optimum lubrication of all moving parts in the gear unit may only work with the machine in a vertical position in Max.
Page 6
LUBRICATION AND MAINTENANCE. Since the machine can be subjected to excessive stress, it is important to look for loose parts, and retighten the bolts periodically. There must be checked for any damage to the machine, and there is no damage to parts that can be replaced with spare parts should be done, any damage discovered must be repaired properly and professionally correct.
