Chapter 5 – Installing and Using the Device

Installing a SIM Card

This model requires a mini (3FF) SIM card, which is supplied by your cellular service provider. To install the SIM
card:
1. Locate the SIM card slot on the side of the modem. The slot is labeled SIM.
2. Slide the SIM card into the SIM card slot with the contact side facing down as shown. When the SIM card
is installed, it locks into place.

Device Phone Number

Every device has a unique phone number. Your cellular service provider supplies a phone number when you
activate your account. Wireless service provider implementation may vary. Consult with your cellular service
provider to get the phone number for your device.

Removing a SIM Card

To remove the SIM card, push the SIM card in. The device ejects the SIM card.

Installing the Device

1. After installing the SIM card, connect the antenna(s) included with your device to the antenna
connector(s).
2. If your device is the serial version:
a. Connect the DE9 male connector (9-pin) of the RS-232 cable to the RS-232 connector on the device,
then connect the other end to the serial port on the other desired device.
b. Screw-on the power lead from the power supply module into the power connection on the device.
c. Plug the power supply into your power source.
3. If your device is the USB version:
a. See the section "USB Cable Recommendations" for information about the USB cable that helps
power your device.
b. The USB cable uses power from the USB power line. Connect one end of the USB cable to your
computer or other USB high power device, such as a hub.
c. Connect the other end to the device's USB connector.
4. The POWER LED lights after the device powers up.
®
