Rage Volitar Instruction Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

INSTRUCTION MANUAL
Specifications
Height:
Total length:
Weight (with battery):
Main Rotor Diameter:
Battery:
Main Motor:
Tail Motor:
Charger:
Transmitter:
Flight Time:
Charge Time:
3.15" (80mm)
10.55" (268mm)
1.86 oz. (52.7g)
9.84" (250mm)
3.7V 1S 300mAh LiPo
8520 Coreless
0615 Coreless
USB cord
4-channel, 2.4GHz
Up to 15 minutes
Approximately 60 minutes

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Volitar and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Rage Volitar

Summary of Contents for Rage Volitar

  • Page 1 INSTRUCTION MANUAL Specifications Height: 3.15” (80mm) Total length: 10.55” (268mm) Weight (with battery): 1.86 oz. (52.7g) Main Rotor Diameter: 9.84” (250mm) Battery: 3.7V 1S 300mAh LiPo Main Motor: 8520 Coreless Tail Motor: 0615 Coreless Charger: USB cord Transmitter: 4-channel, 2.4GHz Flight Time: Up to 15 minutes Charge Time:...
  • Page 2 Volitation is de ned as the act of ying and the new Rage RC Volitar takes the ease of ying a micro heli to a whole new level. The Volitar is equipped with all the features that make RC drones easy to y; like 6-axis ight control, auto take-o and land, altitude hold, and dual ight modes and incorporates them into a micro heli.

  • Page 3: Battery Safety Precautions

    Important Notes, Safety Precautions, and Warnings The manual includes safety information and instructions for the operation and maintenance of this aircraft. Please read the entire manual to understand the functions of this aircraft before any operation. Potential damage to the product and personal injury may occur if the product is not operated correctly.
  • Page 4 Functions Power On LED Auto Take-off and Auto Land Dual Rates (High/Low) Hold for 3 seconds for emergency stop On/Off switch Throttle/Yaw Control Aileron/Elevator Control No function Aileron Trim Yaw Trim Elevator Trim Basic Parts Identification Blade Holder Swashplate Main Blade Rotor Head Main Shaft Tail Rotor...

  • Page 5: Charging Instructions

    Charging Instructions The charging process is completed by plugging the USB connector into a power source, such as a USB port on a computer, a USB adapter into an AC power outlet, or a portable power bank. With all 3 power sources, follow the steps listed below: 1.

  • Page 6: Flight Controls

    Flight Controls Follow the diagrams below for controlling the heli from the transmitter. Descend...
  • Page 7 Binding and Flight Instructions Turn On 1. Connect the battery as shown in the diagram. Note that there is not a cord to plug the battery into the unit. Simply gently slide the battery into the bracket until you feel it lock into place. 2.
  • Page 8 Trimming Instructions The aircraft was set up at the factory for a steady hover. However, if you find that you need to make minor adjustments to maintain a steady hover, the trim buttons can be used as shown in the diagrams below.

  • Page 9: Troubleshooting Guide

    Trouble Shooting Guide The lights on the aircraft and Review step #3 on page 7 of The aircraft has not been transmitter continue to blink the manual and repeat the bound to the transmitter. and the aircraft will not binding process. respond to controls.

  • Page 10: Parts List

    Parts List Item Number Description RGR6000 Volitar RTF Heli RGR6011 Rotor Head (2) RGR6012 Spindle Shaft (2) RGR6013 Spindle Dampeners (4) RGR6014 Spindle Spacers (4) RGR6015 Canopy Grommets (4) RGR6016 Blade Grips (2 sets) RGR6017 Pushrod Linkages (2 sets) RGR6018...

  • Page 11: Replacing Parts

    Replacing Parts Remove damaged blades using a hex wrench. When replacing with new blades, make sure the orientation is correct (as shown) and be careful When replacing the tail assembly, pull firmly backwards, not to overtighten the screws. as shown. When replacing make sure to align the cord in the guide, as shown in the diagram.

  • Page 12: Warranty

    Purchaser’s Remedy - Rage R/C’s sole obligation and purchaser’s sole and exclusive remedy shall be that Rage R/C will, at its option, either (a) service, or (b) replace, any Product determined by Rage R/C to be defective. Rage R/C reserves the right to inspect any and all Product(s) involved in a warranty claim.
