© LOW BATTERY INDICATOR
Appears when the vessel's battery voltage drops below
11 V. (p. 6)
@ VOICE SCRAMBLER INDICATOR
Appears while the optional voice scrambler is activated.
(p. 8)
@ SEND INDICATOR
Appears when DSC information has been transmitted.
(pgs. 13-20)
@ RECEIVE INDICATOR
Appears when DSC information has been received.
(pgs. 13-20)
@® TRANSMIT INDICATOR
Appears while transmitting. (p. 9)
® AUTO FOG HORN INDICATORS
Appear when the auto fog horn function is activated. The
number of indicators varies according to the selected fog
horn type. (p. 24)
@® s/AF INDICATOR
'= Shows the relative signal strength while receiving.
'» Shows whether high or low output power is selected
while transmitting. (pgs. 8, 9)
@ NMEA INDICATOR
Appears when NMEA devices (such as a GPS receiver)
are connected. (p. 35)
PANEL DESCRIPTION 2
@ ALPHANUMERIC READOUT
'» Displays channel names during regular operation.
(p. 12)
'» Displays position and UTC time when [16 *POS] is
pushed for 1 sec. (p. 25)
'» Displays selected functions, DSC information, set mode
items, etc. depending on operation.
