US Robotics Courier USR997748 Specifications

USR9 9 7 74 8
Courier
48-port gigabit smart switch
The new line of USRobotics Courier Gigabit Smart Switches deliver the
performance and manageability required for today's small and medium
business networks. The 48-Port Gigabit Smart Switch supports simple
web-based configuration, port- and tag-based VLAN and four auto-sensing
mini-GBIC ports. It is designed for easy installation, management, and
expansion.
Intelligent Gigabit Networking for Business
Solid Manageability
Flexible Ethernet
Connectivity
Simple, Reliable
Design
Non-Blocking
• Easy Web-based configuration from a Web browser anywhere on the network
• Support for 802.1q VLAN (port- and tag-based)
• Quality of Service (QoS)
• Port mirroring
• Specific port configurations (speed, duplex mode, and device flow control)
• Includes additional configuration and management utility (Windows 2000/XP compatible)
• Supports Ethernet connections at speeds of 10/100 Mbps and 1 Gbps (1000 Mbps)
• Includes four 1000 Mbps mini-GBIC ports for extending distance
• Auto-Speed Detection - each port automatically detects, and matches the speed of connected
Ethernet devices - 10/100/1000 Mbps
• Auto-Switching eliminates the need for cross-over cables
• Metal case & efficient design enhances reliability
• Visual diagnostic LEDs
• Standard 19 inch rack-mount form factor
• Overall throughput that matches the total capacity of the high speed ports (96 Gbps)
10/100/
1000
Mbps
G i g ab it N et wo rk i ng
Auto
OS
MDI/MDIX
48
