US Robotics Courier USR997716 Specifications

USR9 9 7 71 6 & U SR 99 7 7 24
Courier
16-port gigabit smart switch
24-port gigabit smart switch
The new line of USRobotics Courier Gigabit Smart Switches deliver the
performance and manageability required for today's small and medium
business networks. With simple web-based configuration, support for port-
based VLAN and two auto-sensing mini-GBIC ports, they are designed for
easy installation, management, and expansion.
Intelligent Gigabit Networking for Business
Solid Manageability
Flexible Ethernet
Connectivity
Simple, Reliable
Design
Non-Blocking
• Easy Web-based configuration from a Web browser anywhere on the network
• Support for port-based VLAN
• Quality of Service (QoS)
• Port mirroring
• Specific port configurations (speed, duplex mode, and device flow control)
• Includes additional configuration and management utility (Windows 2000/XP compatible)
• Supports Ethernet connections at speeds of 10/100 Mbps and 1 Gbps (1000 Mbps)
• Auto-Speed Detection - each port automatically detects, and matches the speed of connected
Ethernet devices - 10/100/1000 Mbps
• Auto-Switching eliminates the need for cross-over cables
• Metal cases & efficient design enhance reliability
• Visual diagnostic LEDs
• Standard 19 inch rack-mount form factor
• All switches support overall throughput that matches the total capacity of the high speed ports
(32 Gbps for the 16-Port and 48 Gbps for the 24-Port)
10/100/
1000
Mbps
Auto
OS
MDI/MDIX
G i g ab it N et wo rk i ng
16 24
