USR9 9 7 62 4
Courier
24-port poe smart switch
The latest addition to the USRobotics Courier business solutions line, the 24-Port
PoE Smart Switch, provides data connectivity and DC power to Ethernet devices
in difficult to reach locations. Designed with flexibility and expandability in mind,
it supports variable power settings up to 15.4W on the 24 10/100 Mbps ports
(maximum total 170W), and has two Gigabit ports (for uplinks and extending
networking range). Simple to use web-based management makes this an ideal
solution for small and medium businesses.
Power Ethernet devices without adding electrical outlets
DC Power Where You
Need It
Solid Manageability
Flexible Ethernet
Connectivity
Simple, Reliable
Design
Non-Blocking
•
Save money by delivering DC power via Ethernet cabling
•
Support for PoE priority settings so that high priority devices (eg. IP Phones) stay powered in
case of unexpected power drain allowing low priority devices to be powered off if necessary
•
Includes both over current and circuit sorting protection
•
Easy Web-based configuration from a Web browser anywhere on the network
•
Support for port-based VLAN
•
Quality of Service (QoS)
•
Port mirroring
•
Specific port configurations (speed, duplex mode, and device flow control)
•
Includes additional configuration and management utility (Windows 2000/XP compatible)
•
Supports Ethernet connections at speeds of 10/100 Mbps on 24 PoE ports and 10/100/1000
Mbps on 2 Gigabit ports
•
Auto-Speed Detection - each port automatically detects, and matches the speed of connected
Ethernet devices
•
Auto-Switching eliminates the need for cross-over cables
•
Metal case and efficient design enhance reliability
•
Visual diagnostic LEDs
•
Standard 19 inch rack-mount form factor
•
Overall throughput matches the total capacity of the switch ports (8.8 Gbps)
10/100/
PoE
1000
Mbps
Wi red N et wo rk i ng
Auto
OS
MDI/MDIX
24
