- Page 1 CGM Interface Manual, HFR/ NVH (Small Map with Data Exchange) Applications, March 25, 2022, Page 1 of 23...
-
Page 2: Table Of Contents
Appendix B – Data Exchange Interface ...... 12 Data Exchange Interface Pointer Designation Table 13 Appendix C – Error Number Tables: ......18 CGM Interface Manual, HFR/ NVH (Small Map with Data Exchange) Applications, March 25, 2022, Page 2 of 23... -
Page 3: Related Manuals
0 on the mounting dimensions. corresponding Gateway setup screen on the HFR/NVH ADM display module. The Gateway setup screens are described later. CGM Interface Manual, HFR/ NVH (Small Map with Data Exchange) Applications, March 25, 2022, Page 3 of 23... -
Page 4: Setup - Gateway Screens
Connect the other end of the cable to the FieldBus device. Screen 2 This screen displays the hardware revision, system serial number, and data map identification information. CGM Interface Manual, HFR/ NVH (Small Map with Data Exchange) Applications, March 25, 2022, Page 4 of 23... -
Page 5: Devicenet Fieldbus Screen
Fieldbus CGM installed. information. Screen 1 This screen enables the user to set the device address, install date, location tag, function tag, and description. CGM Interface Manual, HFR/ NVH (Small Map with Data Exchange) Applications, March 25, 2022, Page 5 of 23... - Page 6 Screen 2 This screen enables the user to set the station name install date location tag, function tag, and description. CGM Interface Manual, HFR/ NVH (Small Map with Data Exchange) Applications, March 25, 2022, Page 6 of 23...
-
Page 7: Available Internal Data
Sequence Mode). I160 – Current Sequence number (1- I167 26, for A-Z) selected (Sequence mode only) I168 Heart Beat from HFR/NVH MCM (#) CGM Interface Manual, HFR/ NVH (Small Map with Data Exchange) Applications, March 25, 2022, Page 7 of 23... -
Page 8: Output Data (Signals From Plc To Hfr/ Nvh System)
(= 1) to start then release (= 0) and repeat during TBD Bit Command6 dispense to abort if necessary). TBD Bit Command7 TBD Bit Command.8 CGM Interface Manual, HFR/ NVH (Small Map with Data Exchange) Applications, March 25, 2022, Page 8 of 23... -
Page 9: Run Screens Displaying Available Data
Green, and off (low) when the graphic is Grey. Figure 10: New Fieldbus Data “Commands” Screen. Figure 9: New Fieldbus Data “Indications” Screen. CGM Interface Manual, HFR/ NVH (Small Map with Data Exchange) Applications, March 25, 2022, Page 9 of 23... -
Page 10: Appendix A - I/O Signal Descriptions
System Startup Control (I171, O26) Setting this bit (O26) will request the following, based on the figuration of the HFR or NVH system: CGM Interface Manual, HFR/ NVH (Small Map with Data Exchange) Applications, March 25, 2022, Page 10 of 23... -
Page 11: High Pressure Recirculation (I173 And O28)
CGM Interface Manual, HFR/ NVH (Small Map with Data Exchange) Applications, March 25, 2022, Page 11 of 23... -
Page 12: Appendix B - Data Exchange Interface
Note 2: All Read designations on the Data Exchange are assigned and Even numbers, whereas all Write designations are assigned an Odd number assignments. CGM Interface Manual, HFR/ NVH (Small Map with Data Exchange) Applications, March 25, 2022, Page 12 of 23... -
Page 13: Data Exchange Interface Pointer Designation Table
Current Zone Actual Temperature, in 0.1 C units. Read temperature Blue Tank Blanket Zone, Current Zone Actual Temperature, in 0.1 C units. Read temperature CGM Interface Manual, HFR/ NVH (Small Map with Data Exchange) Applications, March 25, 2022, Page 13 of 23... - Page 14 Read Ratios are either volumetric or weight depending upon the “Flow Units” Selection on the ADM Advanced #2 setup screen. CGM Interface Manual, HFR/ NVH (Small Map with Data Exchange) Applications, March 25, 2022, Page 14 of 23...
- Page 15 (Write), the HFR/ NVH will remember the assignment, even (Output instance 8, O88 – after a power cycle. Read O103) Register assignments should be 16 bits wide, or smaller. CGM Interface Manual, HFR/ NVH (Small Map with Data Exchange) Applications, March 25, 2022, Page 15 of 23...
- Page 16 In RPM. Only valid if using Dynamic Mixer (Voltex) option. Read Dynamic Mixer Actual In RPM. Only valid if using Dynamic Mixer (Voltex) option. Read Speed CGM Interface Manual, HFR/ NVH (Small Map with Data Exchange) Applications, March 25, 2022, Page 16 of 23...
- Page 17 Enabled (= 0, if logic is Active). Refer to “Cavitation Errors Disabled” option on ADM Advanced #3 setup screen for Read current state. 273 – Reserved for Future Use 65,xxx Notes: CGM Interface Manual, HFR/ NVH (Small Map with Data Exchange) Applications, March 25, 2022, Page 17 of 23...
-
Page 18: Appendix C - Error Number Tables
Current WSD0 Invalid Gel Timer Definition T4C1 Blue MCM High Temp. DDA1 Red Pump Cavitation V4H0 Blue MCM Overvoltage V1H1 Blue MCM CGM Interface Manual, HFR/ NVH (Small Map with Data Exchange) Applications, March 25, 2022, Page 18 of 23... - Page 19 No Blue Chiller Overvoltage Current V4A7 Red Chiller A4A6 Red Blanket Overvoltage Overcurrent A4B5 Blue Blanket V4B8 Blue Chiller Overvoltage Overcurrent A4A3 Red Inline CGM Interface Manual, HFR/ NVH (Small Map with Data Exchange) Applications, March 25, 2022, Page 19 of 23...
- Page 20 Red Tank Low Fluid Fluid Temp. Temp. T4B1 Blue Inline High T2BD Blue Tank Low Fluid Fluid Temp. Temp. T4A2 Red Hose High Fluid Temp. CGM Interface Manual, HFR/ NVH (Small Map with Data Exchange) Applications, March 25, 2022, Page 20 of 23...
- Page 21 Red Hose Con. T6C6 Red Blanket RTD Fault (Unexpected Fault Relay I) T6C5 Blue Blanket RTD Fault T6C7 Red Tank Monitor RTD Fault CGM Interface Manual, HFR/ NVH (Small Map with Data Exchange) Applications, March 25, 2022, Page 21 of 23...
- Page 22 Comm. Error Red L8A1 Red Fill Sensor Hose Fault CAB4 Comm. Error Blue L8B2 Blue Fill Sensor Hose Fault MMUX V USB: Logs Full CGM Interface Manual, HFR/ NVH (Small Map with Data Exchange) Applications, March 25, 2022, Page 22 of 23...
- Page 23 P2F2 Low Blue Pump Input Pressure P3F1 High Red Pump Input Pressure P3F2 High Blue Pump Input Pressure Questionable Shot Recipe Detected CGM Interface Manual, HFR/ NVH (Small Map with Data Exchange) Applications, March 25, 2022, Page 23 of 23...
