www.jasonl.com.au
ASSEMBLY INSTRUCTIONS
Quadro Square
Quadro Square
Need help!
Counter table
Counter Frame
Call us on
1300 527 665
Sizes: 1200x700, 1400x700, 1600x700, 1800x700 mm
STEP 06
I
TABLE TOP
BOTTOM VIEW
nut insert
nut insert
Place desktop ontop of frame. Nut inserts in top will align with plastic
Place desktop on top of frame. Wood Screws to be drilled into
joiner brackets using M6x30MM (I) sockets attach top to frame.
the underneath Top.
Page 6 of 6
