ASSEMBLY INSTRUCTIONS
Quadro Square
Quadro Square
Need help!
Counter table
Counter Frame
Call us on
1300 527 665
Sizes: 1200x700, 1400x700, 1600x700, 1800x700 mm
F
STEP 04
TOP VIEW
STEP 05
F
Attach beam (C) to legs (B) using nut insert in legs.
Frame looks like this. Using Allen Key, attach beam (C) with Socket (F)
See point attached
Page 5 of 6
