Expression Pedal

Morphing from Heel to Toe
Use an Expression Pedal to change any grouping
of Knob Parameters in one smooth gesture. Easily
Program an Expression Pedal by setting end points for
Heel and Toe. Here's how:
1. Press Exp Pedal fully Heel down.
2. Adjust any combination of Knob Parameters to set
the Heel values.
3. Press Exp Pedal fully Toe down.
4. Adjust any combination of Knob Parameters to set
the Toe values.
5. Save it or lose it. See "Presets. "
Clear Expression Pedal Mappings
To clear the Expression Pedal mappings for all Knob
Parameters, press and hold the Drive Footswitch and,
while holding, press and hold the Drive LED Button
until the Preset Ladder LEDs flash twice.
NOTE: To use an Expression Pedal, the EXP Jack must be
set to either [EXP] or [EXP + AUX] in System Setup.

MIDI Messages

Save Preset
Press and hold the Vibe LED Button to enter Save Mode,
then a MIDI program change message will save a Preset
to the Preset slot of the given value 1–127.
Load Preset
MIDI program change message loads the Preset from
the Preset slot of the given value 1–127. The bottom
two Ladder LEDs will be lit when Presets 6–127 are
selected externally via MIDI.
CC PARAMETER
4 Expression Pedal
9 Tap Rate
14 Pedal Active/Bypass
52 Drive On/Off
Knob Parameters
CC VIBE PARAMETER
20 Vibe
21 Speed
22 Intensity
CC PARAMETER
53 Vibe On/Off
54 Drive Voicing
55 Vibe Voicing
56 Swap Effect Order
CC DRIVE PARAMETER
23 Drive
24 Tone
25 Level
