Vibe Mix
For classic Uni-Vibe:
50% for chorus
100% for vibrato
Drive Amount
0% is cleanest
100% is dirtiest
Preset LED Ladder
Drive LED Button
Green/Red = Drive On
Off = Drive Off
Press to toggle Voicing
Preset Mode: Toggle
Latching/Momentary for
Active/Bypass
Drive Footswitch
On/Off for Drive effect
Preset Mode: Load Preset
and Active/Bypass
Vibe Speed
Modulation rate
QUICK REFERENCE GUIDE
Vibe Intensity
Modulation depth
Swap LED Button
Off = Vibe → Drive
On = Drive → Vibe
Drive Tone
Left is dark, Right is bright
50% is neutral
Drive Level
Vibe LED Button
Green/Red = Vibe On
Off = Vibe Off
Press to toggle Voicing
Press and hold to save Preset
Vibe Footswitch
On/Off for Vibe effect
Press and hold to toggle
Perform and Preset Modes

Advertisement

loading
Need help?

Need help?

Do you have a question about the RIPTIDE and is the answer not in the manual?

Questions and answers

Summary of Contents for Eventide RIPTIDE

  • Page 1 QUICK REFERENCE GUIDE Vibe Mix Vibe Speed Vibe Intensity Swap LED Button Off = Vibe → Drive For classic Uni-Vibe: Modulation rate Modulation depth 50% for chorus On = Drive → Vibe 100% for vibrato Drive Tone Drive Amount Left is dark, Right is bright 0% is cleanest 50% is neutral 100% is dirtiest...
  • Page 2 Two Effects in One Alternate Voicings The perfect pairing of tones to surf the slow vibey Both Drive and Vibe have an alternate voicing that can waves or drive to pulsing depths. be toggled by pressing the LED Buttons above their corresponding footswitch.
  • Page 3 Presets 5 On Board, 127 Via MIDI The current Preset is indicated on the Preset LED Ladder. When a Preset is modified the Preset LED blinks once. Perform and Preset Modes Save Preset Press and hold Vibe Footswitch to toggle between To save one of the five onboard Presets: Perform and Preset Modes.
  • Page 4: Expression Pedal

    Expression Pedal MIDI Messages Morphing from Heel to Toe Save Preset Use an Expression Pedal to change any grouping Press and hold the Vibe LED Button to enter Save Mode, of Knob Parameters in one smooth gesture. Easily then a MIDI program change message will save a Preset Program an Expression Pedal by setting end points for to the Preset slot of the given value 1–127.
  • Page 5: Enter System Setup

    System Setup Enter System Setup To access these Global Settings, apply power while holding Drive Footswitch and Swap LED Button. Top two Preset LEDs are on when in System Setup. Changes are stored as they are made. Cycle power to exit System Setup. Set MIDI Channel Set Bypass Mode Set EXP Pedal Jack...
  • Page 6 Restore Factory Settings: Power on while pressing Drive Footswitch and Drive LED Button Software Update: Power on while pressing Vibe Footswitch and Vibe LED Button Riptide Quick Reference Guide for Firmware v1.0+ Eventide Part#141348 Rev A Eventide is a registered trademark of Eventide Inc.
