- Page 1 UC-2200A Series Quick Installation Guide Version 1.1, November 2023 Technical Support Contact Information www.moxa.com/support 2023 Moxa Inc. All rights reserved. P/N: 1802022220011 *1802022220011*...
-
Page 2: Package Checklist
UC-2200A to a variety of complex communications solutions. Package Checklist Before installing the UC-2200A, verify that the package contains the following items: • UC-2200A Series computer • 3 round stickers for the screws to preventing tampering • Quick installation guide (printed) •... - Page 3 Bottom Panel View Front Panel View - 3 -...
-
Page 4: Led Indicators
LED Indicators Status Function Power Green Power plugged in Power is OFF SW Ready/ Yellow System is ON and the computer is working Programmable normally System is not ready. USB/ Green USB device is connected and working Programmable normally USB device is not connected Green Micro SD card inserted and working Programmable... - Page 5 Installing the UC-2200A DIN-rail Mounting The stainless-steel DIN-rail mounting plate comes attached to the product’s casing (the specification for the screws is M3 x 6 mm). To mount the UC-2200A on to a DIN rail, make sure that the stiff metal spring is facing upwards and follow these steps.
-
Page 6: Connector Descriptions
Wall Mounting (optional) The UC-2200A can be mounted using a wall-mounting kit, which needs to be purchased separately. Follow these steps to mount the computer on to a wall: Step 1: Use four screws (M3 x 4 Step 2: Use another four screws mm) to fasten the wall-mounting (M3 x 6 mm) to mount the brackets on the left panel of the... -
Page 7: Pin Definition
WARNING EXPLOSION HAZARD! Do not disconnect equipment unless the power has been removed or the area is known to be non-hazardous. Grounding the UC-2200A Grounding and wire routing help limit the effects of noise due to electromagnetic interference (EMI). SG: The Shielded Ground (sometimes called Protected Ground) contact is the right-most contact of the 3-pin power terminal block connector when viewed from the angle shown here. -
Page 8: Pin Signal
Micro SD/SIM Card Sockets The UC-2200A comes with a Micro SD socket for storage expansion and a SIM card socket for cellular communication. The Micro SD card and SIM card sockets are located on the lower part of the front panel. To install the cards, remove the screw and the protection cover to access the sockets and insert the Micro SD card or the SIM card into the sockets. -
Page 9: Real-Time Clock
Real-time Clock The real-time clock in the UC-2200A is powered by a lithium battery. We strongly recommend that you do not replace the lithium battery without the help of a Moxa support engineer. If you need to change the battery, contact the Moxa RMA service team. ATTENTION There is a risk of explosion if the battery is replaced with an incorrect type of battery. -
Page 10: Specifications
Specifications Input Current Models Without Built-in LTE: 600 mA @ 12 VDC 300 mA @ 24 VDC Models With Built-in LTE: 900 mA @ 12 VDC 450 mA @ 24 VDC Input Voltage 12 to 24 VDC (3-pin terminal block, V+, V-, SG) Power Models Without Built-in LTE: Consumption... - Page 11 BSMI Certification for Taiwan 限用物質含有情況標示聲明書 Declaration of the Presence Condition of the Restricted Substances Marking 設備名稱: 嵌入式計算機 型號（型式）: UC-2222A-T Equipment name Type designation (Type) 限用物質及其化學符號 Restricted substances and its chemical symbols 單元 Unit 六價鉻 多溴聯苯 多溴二苯醚 鉛 汞 鎘 Hexavalent Polybrominat Polybrominated Lead...
- Page 12 警告：為避免電磁干擾，本產品不應安裝或使用於住宅環境。 警告：更換不正確之電池形式會有爆炸的風險，請依製造商說明書處理用過之電池 製造商：四零四科技股份有限公司 地址：新北市新莊區新北大道 4 段 3 號 13 樓 服務電話：02 8919 1230 이 기기는 업무용 환경에서 사용할 목적으로 적합성평가를 받은 기기로서가정용 환경에서 사용하는 경우 전파간섭의 우려가 있습니다. 상호: Moxa Inc. 기자재 명칭: LTE 이동통신용 무선설비의 기기(기타) 모델명: UC-2222A-T, UC-2222A-T-AP 제조자...
