2.4

S2 DIP Switch

There is one 4-position DIP switches located on the left-bottom corner at reference designator S2. By
default, all of the switches are set to the "OFF" position and should remain in that position when
completing the steps in this user's guide.
SPNU508B – September 2011 – Revised September 2013
Submit Documentation Feedback
Table 2-9. Demo LEDs
Location
Left Top
Top
Right Top
Right Bottom
Bottom
Left bottom
Left
Right
Table 2-10. Other LEDs as Indicator
LED
nERROR
XDS100V2 SCI RX
XDS100V2 SCI TX
XDS100V2 PWRENn
JTAG TDI
Ethernet Speed
ARM JTAG Plugin
VCC_1V2
VCC_5V
VCC_3V3
VCC_12V
1
2
3
4
Figure 2-7. DIP Switch Settings
Copyright © 2011–2013, Texas Instruments Incorporated
Signals
NHET1[17]
NHET1[31]
NHET1[0]
NHET1[25]
NHET1[18]
NHET1[29]
NHET1[27]
NHET1[05]
Color
Blue
Blue
Blue
Blue
Blue
Blue
Blue
Blue
Blue
Blue
Physical Description
S2 DIP Switch
Color
White
White
White
White
White
White
White
White
Red
