ICMflex
Partial discharge and loss factor measurement system
4.2

Setting up a Bluetooth COM port

All Bluetooth devices on computer systems can provide so called virtual COM ports. These COM ports will be
used to establish a connection with the ICMflex. Standard laptops come with built-in Bluetooth interfaces. If
not, it is possible to use external USB-Bluetooth devices. Power Diagnostix can provide such devices for USB,
PCI, or other interfaces, if needed. The Bluetooth interface on any computer provides an automatic scanning
function. Please start this procedure to find the ICMflex Bluetooth device.
Figure 12: Bluetooth connection wizard
The express mode will guide through this setup (Figure 12). Click 'Next'. The search routine can take a few
minutes. A pop-up window will display all devices found in range (Figure 13). Select the 'ICMflex' entry and
continue the installation procedure (Figure 14).
It is mandatory to set the device code (Figure 15) for the ICMflex connection to "0000".
Figure 14: Bluetooth device successfully added
18 User guide for ICMflex
Figure 13: Adding a Bluetooth device
Figure 15: Entering pairing code
