ENGLISH

1. PARTS AND COMPONENTS

The graphics in this manual are schematic representations and may not exactly match the
product.
Fig. 1
1. Start/Pause button
2. Back home button
Back home button
The robot vacuum cleaner will automatically go to the charging base when you press this
button on the robot or on the app.
Indicator light
- Steady orange light: low battery/back home mode.
- Flashing orange light: charging.
- Steady blue light: fully charged/standby mode/cleaning.
- Oscillating/steady red light: error/tank missing.
Start/Pause button
1. Hold down this button for a few seconds to turn the robot on or off.
2. Press it to start cleaning too.
Fig. 2
1. Anti-collision sensor
2. Power switch
Fig. 3
1. Free-fall sensors
2. Driving wheels
3. Charging terminals
4. Omnidirectional wheel
5. Side brushes
6. Battery
7. Mixed tank
8. Jalisco brush
Charging base. Fig. 4
1. Charge indicator
2. Remote control holder
