- Page 1 GAR75 & A s s e m b l y I n s t r u c t i o n s O W N E R ’ S M A N U A L V. GAR75-20231004...
- Page 2 W a r n i n g , S a f e t y & M a i n t e n a n c e Be sure that all users carefully read and understand all warning, safety and maintenance labels on the machine before each use.
-
Page 3: Table Of Contents
T a b l e o f C o n t e n t s • SAFETY INSTRUCTIONS......PAGE 4 • PREPARATION..........PAGE 5 • HARDWARE ILLUSTRATION......PAGE 6 • PART / LIST ILLUSTRATION......PAGE 7 • ASSEMBLY INSTRUCTIONS......PAGE 8 • EXPLODED VIEW.......... -
Page 4: Safety Instructions
Read each step in the assembly instructions and 1. Model Number follow the steps in sequence. Do not skip ahead. 2. Place of Purchase If you skip ahead, you may learn later that you 3. Serial Number (S/N) have to disassemble components and that you 4. Part # and Description may have damaged the equipment. m Assemble and operate the GAR75 on a solid, level surface. Locate the unit a few feet from the walls or furniture to provide easy access. -
Page 5: Preparation
P r e p a r a t i o n Thank you for purchasing the GAR75. This bench is part of the Body-Solid line of quality strength training machines, which lets you target specific muscle groups to achieve better muscle tone and overall body conditioning. To maximize your use of the equipment please study this Owner’s Manual thoroughly. Required Tools Assembly Tips The basic tools that you must obtain before assembling Read all “Notes” on each page before beginning each the GAR75 include but are not limited to: step. While you may be able to assemble the GAR75 using the m Metric Allen Key Set illustrations only, important safety notes and other tips are included in the text. -
Page 6: Hardware Illustration
G A R 7 5 H a r d w a r e I l l u s t r a t i o n Part #1 SOCKET HEAD CAP SCREW M8X45mm QTY. 24 Part #2 FLAT WASHER M8 QTY. 24 Part #3 BARREL NUT M8 QTY. 24 ... -
Page 7: Part / List Illustration
G A R 7 5 P a r t s L i s t / I l l u s t r a t i o n Part# Description BOTTOM TRAY TRAY LEFT UPRIGHT CENTER UPRIGHT RIGHT UPRIGHT HOOK M8X45mm SOCKET HEAD CAP SCREW M8 FLAT WASHER M8 BARREL NUT... -
Page 8: Assembly Instructions
S T E P Be careful to assemble all components in the sequence they are presented. NOTE: Wrench tighten ALL hardware at the end of STEP 1B. Some components may be pre-assembled. Nylon lock nuts will not fully screw onto bolts, they must be wrench tighten to fully go on. - Page 9 S T E P Above shows Step 1 assembled and completed.
- Page 10 S T E P Be careful to assemble all components in the sequence they are presented. NOTE: Wrench tighten ALL hardware at the end of STEP 2A. Some components may be pre-assembled. Nylon lock nuts will not fully screw onto bolts, they must be wrench tighten to fully go on.
- Page 11 S T E P Above shows Step 2 assembled and completed.
- Page 12 N o t e s...
-
Page 13: Exploded View
G A R 7 5 E x p l o d e d V i e w... -
Page 14: Contact Page
GAR75 PLEASE WRITE YOUR SERIAL NUMBER IN THE BOXES BELOW 018549-��-��-����-���� S/N # 1900 S. Des Plaines Ave. Forest Park, IL 60130 Phone:(708)427-3555 Fax:(708)427-3556 Hours: M-F 8:30 - 5:00 CST www.bodysolid.com Copyright 2009. Body-Solid. All rights reserved. Body-Solid reserves the right to change design and specifications when we feel it will improve the product.
