Toyota PTS21-21070 Manual

Toyota PTS21-21070 Manual

Illuminated door sills scion tc 2008-
Hide thumbs

Advertisement

Quick Links

Download this manual
SCION
Preparation
Part Number: PTS21-21070
Kit Contents
Item #
Quantity Reqd.
1
2
2
1
3
1
Hardware Kit Contents (LH)
Item #
Quantity Reqd.
1
1
2
2
3
1
4
12
6
2
Hardware Kit Contents (RH)
Item #
Quantity Reqd.
1
1
2
2
3
1
4
27
6
1
Additional Items Required For Installation
Item #
Quantity Reqd.
Conflicts
None
Recommended Tools
Personal & Vehicle
Protection
Safety Glasses
Safety Gloves
Vehicle Protection
Protective film
Special Tools
Non-intrusive temperature
probe
Blow Drier
Installation Tools
Nylon Panel Removal Tool
Screwdriver
Ratchet
Extension
Socket
Torque Wrench
Non-scratch wiping cloth
Pliers
Issue: C 06/13/07
tC
Description
Hardware Kit w/ power harness
Front Left Illuminated Door Sill
Protector
Front Right Illuminated Door
Sill Protector
Description
Power Harness with Fuse
Foam Pad (38.1 x 38.1 x 4.75)
Foam Pad (63.5 x 38.1 x 1.57)
Wire Ties
T-taps
Description
Power Harness
Foam Pad (38.1 x 38.1 x 4.75)
Foam Pad (63.5 x 38.1 x 1.57)
Wire Ties
T-taps
Description
Notes
Optional
Blankets, Part Boxes,
PPO only, Wrap Guard
Notes
For measuring door sill
temperature if necessary
For cold temperature
installations.
Notes
Phillips head #2
6 in
10 mm (deep socket)
36 lbf-in
3M Micro-fiber
Page 1 of 17 pages
2008-
ILLUMINATED DOOR SILLS
NOTE: Part number of this accessory may not be
the same as the part number shown.
Wire Cutters
Special Chemicals
All Purpose Cleaner
General Applicability
2008 SCION - tC
Recommended Sequence of Application
Item #
Accessory
1
V5 Security – RS3200 +
2
Illuminated Door Sills
3
Audio
4
Satellite Radio
5
Interior Light Kit
Vehicle Service Parts
Item #
Quantity Reqd.
Legend
STOP: Damage to the vehicle may occur. Do not
proceed until process has been complied with.
OPERATOR SAFETY: Use caution to avoid risk of
injury.
CAUTION: A process that must be carefully observed
in order to reduce the risk of damage to the
accessory/vehicle and to ensure a quality installation.
TOOLS & EQUIPMENT: Used in Figures calls out the
specific tools and equipment recommended for this
process.
Notes
mild water based, solvent
free all purpose cleaner.
(may be required for reassembly)
Description

Advertisement

loading
Need help?

Need help?

Do you have a question about the PTS21-21070 and is the answer not in the manual?

Questions and answers

Related Manuals for Toyota PTS21-21070

Summary of Contents for Toyota PTS21-21070

  • Page 1 SCION 2008- ILLUMINATED DOOR SILLS Preparation NOTE: Part number of this accessory may not be Part Number: PTS21-21070 the same as the part number shown. Wire Cutters Kit Contents Item # Quantity Reqd. Description Hardware Kit w/ power harness Special Chemicals...
  • Page 2 Vehicle Disassembly/Reassembly (panel removal, part storage, etc.). • Electrical Component Disassembly/Reassembly (battery disconnection, connector removal, etc.). Please see your Toyota dealer for a copy of this document. 1. Vehicle Disassembly (a) Remove the negative battery cable. (Fig. 1-1) (1) For vehicles equipped with automatic...
  • Page 3 SCION 2008- ILLUMINATED DOOR SILLS Procedure Nylon Panel Removal Tool (d) Remove the glove box under panel. (Fig. 1-4) Glover Box Under Panel Fig. 1-4 Nylon Panel Removal Tool (e) Remove the driver and passenger side cowl cover. (Fig. 1-5) Cowl Cover (1) Remove the one nut securing the cowl cover.
  • Page 4 SCION 2008- ILLUMINATED DOOR SILLS Procedure Phillips Screwdriver (h) Remove two screws securing the lower steering column cover behind the steering wheel. (Fig. 1-8) (1) Insert the key into the ignition switch and turn it to ON to unlock the steering wheel.
  • Page 5 SCION 2008- ILLUMINATED DOOR SILLS Procedure Cigarette Lighter Connector (l) Carefully lift up the center console panel and disconnect the cigarette lighter connector and Harness the harness clip. Set console panel aside. Clip (Fig. 1-12) Fig. 1-12 Nylon Panel Removal Tool Center Cluster Panel (m) Remove the center cluster panel.
  • Page 6 SCION 2008- ILLUMINATED DOOR SILLS Procedure Pliers (c) Locate and remove the blue 22 pin connector located at the driver side cowl area. (Fig. 2-2) (d) Install a T-Tap to the orange wire (pin #1) on the 22 pin connector, about 1 inch from the connector end.
  • Page 7 SCION 2008- ILLUMINATED DOOR SILLS Procedure (i) Locate the driver side illuminated door sill. Remove tape liner from back of lighted side sill. (Fig. 2-5) Tape Liner (j) Install lighted side sill to vehicle. (1) The word “SCION” should be right side Fig.
  • Page 8 SCION 2008- ILLUMINATED DOOR SILLS Procedure Wire Cutters (m) Secure the power wire from the lighted side sill to vehicle harness using a wire tie. Wire tie (Fig. 2-9) Fig. 2-9 (n) Route lighted side sill harness toward front Wire Cutters of car along side of vehicle harness.
  • Page 9 SCION 2008- ILLUMINATED DOOR SILLS Procedure Wire Cutters (c) Route the power harness to the vehicle Fuse Holder harness behind the connector block as Wire Wire Ties shown. (Fig. 3-3) (1) Secure both sides of the fuse with two Wire Tie wire ties.
  • Page 10 SCION 2008- ILLUMINATED DOOR SILLS Procedure Wire Cutters Junction block (g) Secure harness to vehicle harness, using one wire tie as shown. (Fig. 3-7) Harness wire Wire tie Fig. 3-7 4. Install Passenger Crossover Harness. (a) Attach crossover male connector to Power Connectors harness female connector and wrap with the thick foam tape.
  • Page 11 SCION 2008- ILLUMINATED DOOR SILLS Procedure Wire Cutters (d) Route the Crossover harness toward the center console area. (Fig. 4-4) (1) Route the Crossover harness through the opening space in front of the driver side Foam brace as shown. Crossover Harness Brace (2) Install thick foam tape to brace to protect...
  • Page 12 SCION 2008- ILLUMINATED DOOR SILLS Procedure Crossover Wire Cutters (h) Route the Crossover harness through the Harness glove box area, then secure it to the vehicle harness with three wire ties. (Fig. 4-8) Crossover Wire Ties Harness Fig. 4-8 (i) Continue to route the crossover harness down Wire Cutters to the passenger side connector block.
  • Page 13 SCION 2008- ILLUMINATED DOOR SILLS Procedure Weather Stripping 5. Install Passenger Side Door Sill (a) Lift up the passenger side door weather stripping. (Fig. 5-1) (b) Locate the crescent shaped depression on the pinch weld. Clean the pinch weld surface Fig.
  • Page 14 SCION 2008- ILLUMINATED DOOR SILLS Procedure Locator Pin (f) Install lighted side sill to vehicle. (1) The word “SCION” should be right side up reading from the outside of the vehicle. Alignment Hole (2) Be sure locating pin aligns correctly with vehicle alignment holes.
  • Page 15 SCION 2008- ILLUMINATED DOOR SILLS Procedure (k) Place a protective blanket on top of the side sill. Wire Cutters (l) Connect crossover harness to sill harness. (1) Wrap connector with the thick foam tape and secure the harness with three wire Wire Ties ties as shown.
  • Page 16 SCION 2008- ILLUMINATED DOOR SILLS Procedure (g) Reinstall the driver and passenger side cowl cover and door scuffs. (h) Reinstall the glove box under panel. (i) Reconnect the vehicle’s negative battery cable. (1) Position the negative battery cable at the original factory position.
  • Page 17 SCION 2008 - ILLUMINATED DOOR SILLS Checklist - these points MUST be checked to ensure a quality installation. Check: Look For: Accessory Function Checks Open the door. Door sill light should turn on. Close the door. Door sill light should turn off. Vehicle Function Checks Interior lights.
