Summary of Contents for Toyota PVM
- Page 1 FORTUNER - JAN - 2021 - 001 PANORAMIC VIEW MONITOR (PVM) OWNERS MANUAL Please read this manual for proper operation and keep it for future reference.
-
Page 2: Table Of Contents
FORTUNER - JAN - 2021 - 001 TABLE OF CONTENTS PANORAMIC VIEW MONITOR (FORTUNER) Section Title Page Statements & Declarations Safety Instructions Getting Started Product Overview Operating Panoramic View Monitor Gear : Engaged to Parking (P) / Neutral (N) / Drive (D) 2D model + 3D model 360˚. -
Page 3: Statements & Declarations
Read, follow, and retain all of the following safety precautions. Heed all warnings before operating the Panoramic View Monitor. Cautions 1. Several precautions are to be taken whle using the PVM : a. PVM function automatically disables when vehicle speed exceeds 12 km/h. -
Page 4: Getting Started
FORTUNER - JAN - 2021 - 001 SECTION 2.0 Getting Started Product Overview • Figure 2.1 Front Camera Fortuner 2.4 & 2.7 • Front camera located at Front Grille (Fortuner 2.4 & 2.7 variant only) Front Camera Fortuner 2.8 •... -
Page 5: Gear : Engaged To Parking (P) / Neutral (N) / Drive (D)
2D model + 3D model (from angle A) . vii. Front view full screen. viii.Rear view full screen. Press and hold PVM button for 3 seconds to exit PVM mode manually. Please read this manual for proper operation and keep it for future reference. -
Page 6: Model + 3D Model 360
Operating PVM 3.1.1 2D model + 3D model 360° view 3D model will rotate for 1 cycle clockwise automatically in a duration of 10 seconds upon manual activation of PVM 3.1.2 2D model + 3D model from angle B 3.1.3 2D model + 3D model from angle D Please read this manual for proper operation and keep it for future reference. -
Page 7: Model + 3D Model From Angle F
FORTUNER - JAN - 2021 - 001 SECTION 3.0 Operating PVM 3.1.4 2D model + 3D model from angle F 3.1.5 2D model + 3D model from angle H 3.1.6 2D model + 3D model from angle A Please read this manual for proper operation and keep it for future reference. -
Page 8: Front View Full Screen
FORTUNER - JAN - 2021 - 001 SECTION 3.0 Operating PVM 3.1.7 Front View Full Screen 3.1.8 Rear View Full Screen Please read this manual for proper operation and keep it for future reference. -
Page 9: Gear : Reverse (R)
Gear : Reverse (R) When gear is engaged to Reverse (R), the screen on head display unit will switch to PVM mode automatically. 2. User can switch between 3 views when gear is engaged to Reverse R). i. 2D model + Rear view. -
Page 10: Rear View Full Screen
FORTUNER - JAN - 2021 - 001 SECTION 3.0 Operating PVM 3.2.2 Rear View Full Screen 3.2.3 2D model + 3D model from view E Please read this manual for proper operation and keep it for future reference.
