BIS-411 1R1Z can't work with backlit buttons.
1-3
power supply of the relay 9÷30 V AC/DC
6
control input
7-9
output – NC contact (passive)
10-12
output – NO contact (active)
Example of connection
Different supply voltages for the relay and receiver
- 3 -
