Check Point QUANTUM FORCE 19000 Getting Started Manual page 45

Item Component
3 2 Storage devices
4 Service tag
5 ESD grounding
point
6 LOM port
7 RJ45 Console port
and
2 USB 3.2 Gen
1x1 ports
8 2 Synchronization
ports
9 2 Management
ports
Description
n Activity LED (on the left):
Off - No storage device activity
l
On (Amber rapid blinking) - Storage device
l
activity
On (Amber slow blinking) - Storage device idle
l
Power LED (on the right):
n
Off - Storage device power is off
l
On (Green) - Storage device power is on
l
A slide-out card that identifies the appliance and shows its
serial number and MAC address.
It also contains a QR code that you can scan to onboard the
appliance and view documentation.
When you service the appliance, connect an ESD strap to
this point.
LOM (Lights Out Management) port to connect to the LOM
Card.
Note - In 19200 / 29100 / 29200 Base appliances, LOM
Card is optional.
RJ45 port for a serial connection to the appliance.
The USB 3.2 Gen 1x1 ports are backwards compatible to
USB 2.0.
Ports for cluster synchronization.
Configuration options:
n Use one of these ports - Sync or Sync2.
n Create a bond on these two ports (Sync and Sync2)
for sync redundancy.
See "Synchronization Port LEDs" on page 47
Ports to manage the Gaia Operating System on this
appliance.
Configuration options:
n Use one of these ports - Mgmt or Mgmt2.
n Create a bond on these two ports (Mgmt and Mgmt2)
for redundancy.
See "Management Port LEDs" on page 47
Quantum Force 19000 and 29000 Appliances Getting Started Guide | 45
19000 / 29000 Appliances Hardware
.
.
