LED signalling
The status of the module can be directly assessed by the STATUS
light located on the front of the device.
The grey color actually corresponds to the green LED
and the black color to the red LED.
Controller
in factory mode
Connecting to
a Wi-Fi network
Connection to Wi-Fi
network established
No connection
to Wi-Fi network
Restoring firmware
- 11 -
