PF-431-LED TRMS
Automatic
phase switch
Do not dispose of this device in the trash along with other waste! According to the Law on
Waste, electro coming from households free of charge and can give any amount to up to
that end point of collec� on, as well as to store the occasion of the purchase of new equip-
ment (in accordance with the principle of old-for-new, regardless of brand). Electro thrown
in the trash or abandoned in nature, pose a threat to the environment and human health.
Purposee
The PF-431-LED True RMS automatic phase switch is used to ma-
intain the continuity of power supply of single-phase receiver. In
the event of supply phase loss or if the phase exceeds the correct
voltage values, a different phase with the correct parameters will
be directed to the output.
By measuring the RMS value of the voltage (True RMS), the swi-
tch guarantees the correct operation even when operating with
a severely disturbed power supply network.
The "LED" version of the relay is equipped with a contact
designed to cooperate with receivers with high starting
current, such as: LED fluorescent lamps, ESL fluorescent
lamps, electronic transformers, discharge lamps, etc.
F&F Filipowski L.P.
Konstantynowska 79/81, 95-200 Pabianice, POLAND
phone/fax (+48 42) 215 23 83 / (+48 42) 227 09 71
www.fif.com.pl; e-mail: biuro@fif.com.pl
- 1 -

Advertisement

loading
Need help?

Need help?

Do you have a question about the PF-431-LED TRMS and is the answer not in the manual?

Questions and answers

Summary of Contents for F&F PF-431-LED TRMS

  • Page 1 Konstantynowska 79/81, 95-200 Pabianice, POLAND phone/fax (+48 42) 215 23 83 / (+48 42) 227 09 71 www.fif.com.pl; e-mail: biuro@fif.com.pl PF-431-LED TRMS Automatic phase switch Do not dispose of this device in the trash along with other waste! According to the Law on Waste, electro coming from households free of charge and can give any amount to up to that end point of collec�...
  • Page 2 Functioning A three-phase voltage is applied at the input of the switch. Voltage of one of the phases is applied at the output of the switch. The electronic system of the switch controls RMS values of the applied phase voltages so that the output voltage is not lower than 190 V or higher than 280 V.
  • Page 3 Prolonged operation with incorrectly connected neutral wire can cause irreparable damage to the controller. The device also monitors the voltage at the output contact, which allows you to detect the „gluing” of the internal relay con- tacts. If this situation is detected, all 3 LEDs will flash cyclically. The protection works only when switching from a lo- wer priority phase to a phase with a higher priority (for example from L2 to L1).
  • Page 4: Wiring Diagram

    Wiring diagram The outputs 9, 10, 11 are connected in parallel, which means that the output signal is available on each of them. - 4 -...
  • Page 5 power supply input – L1 phase power supply input – L2 phase power supply input – L3 phase power supply input – neutral N-wire 9-11 power supply output Technical data input voltage 3×400 V+N output voltage 230 V AC maximum load current (AC-1)* 16 A (120 A/20 ms)** minimum voltage value L1, L2, L3 190 V...
  • Page 6: Power Table

    Power table Table for loads supplied with 230 V AC: tungsten halogen fluorescent energy-saving 3000 W 2500 W 1500 W 750 W 750 W The above data are indicative and will heavily depend on the design of a specific receiver (that is especially important for LED bulbs, energy-saving lamps, electronic transformers and pulse power supply units), switching frequency and operating conditions.
