F&F PF-421 TRMS Manual

Automatic phase switch with the adjustable lower and upper voltage threshold

Advertisement

Quick Links

PF-421 TRMS
Automatic phase switch with
the adjustable lower and upper
voltage threshold
Do not dispose of this device in the trash along with other waste!
According to the Law on Waste, electro coming from households free of charge and can
give any amount to up to that end point of collec� on, as well as to store the occasion of
the purchase of new equipment (in accordance with the principle of old-for-new, regar-
dless of brand). Electro thrown in the trash or abandoned in nature, pose a threat to the
environment and human health.
Purpose
The PF-421 automatic phase switch is used to maintain the con-
tinuity of the power supply of a single-phase receiver in case of
phase failure or when the phase exceeds preset parameters. The
compact size of the device allows you to save space in the elec-
trical cabinet.
By measuring the RMS value of the voltage (True RMS),
the switch guarantees the correct operation even when
operating with a severely disturbed power supply net-
work.
Functioning
A three-phase voltage (3×230 V+N) is connected to the input ter-
minals of the device. A single-phase voltage (230 V) of one of the
phases appears at the output of the relay. The electronic circuit
of the switch controls the voltage values of the supplied phases
so that the output voltage is not lower or higher than the set
F&F Filipowski sp. j.
Konstantynowska 79/81, 95-200 Pabianice, POLAND
phone/fax (+48 42) 215 23 83 / (+48 42) 227 09 71
www.fif.com.pl; e-mail: biuro@fif.com.pl
- 1 -

Advertisement

loading
Need help?

Need help?

Do you have a question about the PF-421 TRMS and is the answer not in the manual?

Questions and answers

Summary of Contents for F&F PF-421 TRMS

  • Page 1 F&F Filipowski sp. j. Konstantynowska 79/81, 95-200 Pabianice, POLAND phone/fax (+48 42) 215 23 83 / (+48 42) 227 09 71 www.fif.com.pl; e-mail: biuro@fif.com.pl PF-421 TRMS Automatic phase switch with the adjustable lower and upper voltage threshold Do not dispose of this device in the trash along with other waste! According to the Law on Waste, electro coming from households free of charge and can give any amount to up to that end point of collec�...
  • Page 2 values. The phase with the correct parameters is directed to the output Switch. The device measures the RMS value (True RMS) of the voltage, so it is perfect for modern automation systems, where the supply voltage is often distorted due to the operation of nearby devices with pulse power supplies.
  • Page 3 If the output phase voltage is 10 V below the set value or 10 V above it, the switchover will occur with a 10-second delay. If the phase value goes beyond this range, it will be disconnected immediately (about 200 ms). In both cases, when the voltage of either phase is not in the cor- rect range, the output load is disconnected.
  • Page 4 Time courses - 4 -...
  • Page 5 - 5 -...
  • Page 6: Front Description

    Front description Mounting 1. Turn off the power supply. 2. Connect the input voltages to terminals 1, 2, 3 and the neutral wire to terminal 4. 3. Connect the powered single-phase circuit to terminal 5 or 6 (phase) and 7 or 8 (neutral wire). 4.
  • Page 7: Wiring Diagram

    Wiring diagram power supply input – phase L1 power supply input – phase L2 power supply input – phase L3 power supply input – neutral wire power supply output – phase L’ power supply output – neutral wire - 7 -...
  • Page 8 Outputs 5-6 and 7-8 are connected in parallel, which means that the output signal is available on each output. Technical data power supply voltage 3×230 V+N minimum operating voltage (with power from a single phase) 85 V maximum phase voltage 420 V frequency 45÷55 Hz...
  • Page 9: Warranty

    Warranty F&F products are covered by a 24-month warranty from the date of purchase. The warranty is only valid with proof of purchase. Contact your dealer or contact us directly. CE declaration F&F Filipowski sp. j. declares that the device is in conformity with the essential requirements of The Low Voltage Directive (LVD) 2014/35/EU and the Electromagnetic Compatibility (EMC) Directive 2014/30/UE.
