- Page 1 Thermal Imaging Camera IR0019 New Version Instruction Manual...
-
Page 2: Table Of Contents
Contents ................. 2 - 3 1. Overview ............ 4 2. Considerations and Safety Maintenance ............5 - 6 3. Performance Index ............. 7 - 9 4. Product Features ..............10 5. Initial Operation ............. 11 6. Image Registration ............... 12 7. -
Page 3: Overview
1. Overview IR0019 is an infrared camera that integrates surface temperature measurement and real-time thermal image. With this product, the potential problems can be identi ed on the color display screen which is helpful for users to locate the problem, take readings and solve the issue. - Page 4 Night vision: Measuring the electromagnetic energy given o when objects emit heat, the IR0019 translates those energy into visible light for users to see them in the dark. Building inspection: Check that heat is retained uniformly in a building.
-
Page 5: Considerations And Safety
2. Considerations and Safety Maintenance Please read the instructions carefully so as to ensure accurate measurement results and safety: DANGER Do not use the device in When the product works, there is a tiny clicking sound every explosive, ammable or several seconds. -
Page 6: Performance Index
3. Performance Index Display screen 3.2” full angle TFT display screen Infrared image resolution 320 × 240 LCD resolution 320 × 240 Visible image resolution 640x480 (300,000 pixel) Field angle/shortest focus length 27°× 35°/0.5m Thermal sensitivity 0.07°C Temperature measurement range -20~300°C (-4°F~572°F) Test and measurement precision ±2°C or ±2%... - Page 7 Relative humidity < 85％RH Higher Energy Wavelength (µm) Lower Energy LWIR: thermal infrared radiation Infrared Microwaves ◄ ► ◄ ► ◄ ► SWIR MWIR LWIR Wavelength coverage of thermal infrared radiation 0.75µm 1µm 2.7µm 3µm 5µm 8µm 14µm of IR0019...
-
Page 8: Product Features
4. Product Features 4.1. Physical features Visible light camera Infrared imaging sensor Image capture trigger Micro USB... - Page 9 4. Product Features 4.2. Key description Central point temperature cursor This pointer will always remain at the centre of the screen and allow the user to move the camera to identify the temperature of where they point. Thermal point temperature cursor This pointer will automatically locate and display the highest temperature on the screen.
- Page 10 4. Product Features 4.3. Button features ENTER MENU SELECT On/o key Enter key Navigation key: Up, Menu/No key down, left and right Select/Yes key...
-
Page 11: Initial Operation
Press “ ▲” again to display the bottom bar. Image export: use the Micro USB cable to connect the IR0019 to a computer to transfer the les. Record video: Long press the image capture button, the screen will prompt “record video?”, if you select “Yes”... -
Page 12: Image Registration
6. Image Registration The location of the visible light camera is above the infrared imaging sensor which is at the centre of the camera. Together they produce an image overlay (in between visible light mode and infrared mode) which would show the visible light image over the infrared image just like the left image below. -
Page 13: Color Palette
7. Color Palette The menu of color palette can change the false color on the display screen or capture infrared image. There are ve types of color palettes provided: spectra, iron, cool, black and white . Suitable selection of color palette displays the details of the target objective better: Spectra, iron and cool color •... -
Page 14: Application Of Color Palette
8. Application of Color Palette and Image Check/ Deletion 8.1. Application of color palette Color Palette SPECTRA IRON COOL WHITE BLACK Press “MENU ” to select; Select “color palette”and press “ ►” to enter the color palette list. Press “▲”and “ ▼” to select color palette. Press “SELECT”... - Page 15 8. Application of Color Palette and Image Check/ Deletion 8.2. Check images/Delete images Images 171229-105030 171229-105031 171229-105032 171229-105033 171229-105034 Select the images menu and press “ ►” to enter the image menu Press “▲ ”/“▼ ” to adjust the selected items. Press “SELECT”...
-
Page 16: Measure Objects
9. Measure Objects According to the characteristics of the objects and surfaces to be measured, users may select corresponding measurement modes or enter “advanced” option to adjust the value of emissivity (please refer to the table of “emissivity of common materials”). The operating step is as the following: Measure Select the “measure objects”;... -
Page 17: Emissivity
10. Emissivity Emissivity The emissivity of the surface of a material is its e ectiveness in emitting energy as thermal radiation. The emissivity of the product can be adjusted from 0.10 to 1.00 with the default value of 0.95. Many common objects and materials (such as timber, water, skin and textile fabric) will re ect heat energy, so it is easy to obtain high accuracy as a result. -
Page 18: The Table Of Emissivity Value
11. The Table of Emissivity Value The product is provided with four types of object measurement modes: Coarse object (easy to give out energy)(0.95); Semi-matte object (0.80); Semi-shiny object (0.60); Shiny object (0.30); Substance Thermal Substance Thermal radiation radiation Bitumen 0.90-0.98 Black cloth 0.98... -
Page 19: Introduction To "Setting
12. Introduction to “Setting” Sub-menu Settings Auto shutdown ► 5 min 20 min Display intensity ► Medium High English Language ► Chinese Italian German Unit ► Celsius Fahrenheit 24 Hours Time format ► AM/PM Year 2017 Month Set time ► Hour Minute Second... -
Page 20: Time Setting
13. Time Setting / 14. Capture Thermal Points 13. Time Setting Set Time Year 2018 Month Hour Minute Second Press “ ▲”/“ ▼” to select year/month/day/hour/minute. Press “SELECT” to enter edit. Press “ ◄” and “ ►" to select the gure to be changed. Press “... -
Page 21: Video" Sub-Menu
15. "Video" Sub-menu 15.1. View Video Images 171229-105030 171229-105031 171229-105032 171229-105033 171229-105034 Press the “ ► ” key to enter the video list, press the “ ▲ ” “ ▼” keys in the navigation keys to select a video, and then press the “ SELECT ” key to view the video. -
Page 22: Thermal Imaging Image
16. Thermal Imaging Image Analysis Software Operation Guide Software Installation And Operation Connect the product with a USB cable, and then connect to the computer. Open the removable disk in the computer, nd the "INSTALLATION PACKAGE" folder and open it, and click to install the software. - Page 23 16. Thermal Imaging Image Analysis Software Operation Guide Interface Introduction Select the language in the upper right corner of the interface, you can choose Chinese, English, and switch between the two languages. On the right are shown as: fusion rate, color palette, temperature unit, picture information •...
- Page 24 16. Thermal Imaging Image Analysis Software Operation Guide Icon Introduction " " icon, take the temperature of the thermal image. " " icon, select the maximum temperature and minimum temperature of the thermal image in a straight line. " " icon, select the thermal imaging map to select the maximum temperature and minimum temperature.
- Page 25 For B2B or project-based application, please send an email: sales@perfectprime.com FOR MORE INFORMATION ABOUT PERFECT PRIME PLEASE VISIT OUR ABOUT US PAGE AND FEEL FREE TO BROWSE. 製品マニュアルページのQRコードをスキャンする （特定の製品で利用可能な多言語） Scan QR Code for the Product Manual page...
- Page 26 Tyche Smart Limited Retailer Email cs@perfectprime.com 2nd Floor, 107 Charterhouse Street, EC1M 6HW, London, Address England UNITED KINGDOM +44 203 7695377 Telephone...
