- Page 1 Thermal Imaging Camera Instruction Manual: IR0002 www.perfectprime.com for product register and warranty...
-
Page 2: Table Of Contents
Contents 1. Overview---------------------------------------------------------------------------------------3 2. Considerations and Safety Maintenance---------------------------------------------------4 3. Performance Index----------------------------------------------------------------------------5 4. Product Features-------------------------------------------------------------------------------6 5. Menu Description-----------------------------------------------------------------------------7 6. Basic Opertaions------------------------------------------------------------------------------8 7. Time setting------------------------------------------------------------------------------------9 8. Measurement-----------------------------------------------------------------------------------9 9. Color palette----------------------------------------------------------------------------------10 10. Temperature of reflective background--------------------------------------------------10 11. Marking of spot temperature------------------------------------------------- ------------11 12. Image mixing-------------------------------------------------------------------------------11 13. -
Page 3: Overview
The product has a visual camera integrated to increase the differentiation degree. The thermal images and full vision images can be stored in the detachable memory card. IR0002 can store up to 25,000 images on the micro SD card. The image can be stored in PC to generate a report and print. -
Page 4: Considerations And Safety Maintenance
2. Considerations and Safety Maintenance Please read the instructions carefully so as to ensure accurate measurement results and safety: Do not use the device in explosive, flammable or corrosive environments. Since the product is a precision electronic and sensitive optical device. Do not drop it or allow impacts to occur to prevent damage ... -
Page 5: Performance Index
CE (EN61326-1:2006) Warranty period 2 years Size 212×95×62mm Weight 320g ± Work temperature -5℃ to 40℃ ± Storage temperature -20℃ to 50℃ Humidity 10% RH to 80% RH LWIR: thermal infrared radiation Wavelength coverage of thermal infrared radiation of IR0002... -
Page 6: Product Features
4. Product Features Item Description Item Description TFT HD color screen Infrared imagery sensor ① ⑥ Power-on/menu key Visible light camera ② ⑦ Battery cover LED lighting lamp ③ ⑧ Selection/enter key Image captures key ④ ⑨ Small SD card Installation port of tripod ⑤... -
Page 7: Menu Description
5. Menu Description Time setting Save image Background light setting Temperature unit setting ℃ Background temperature setting ℃ Capacity of memory card Color palette setting Emissivity setting... -
Page 8: Basic Opertaions
6. Basic Operations 6.1. Elimination of noise 1. Start up the instrument. 2. Put the head of sensor close to the worktop. 3. Press “ ” key for 5 seconds to eliminate the noise. 6.2. LED light Press “image capturing” key for 5 seconds to turn on LED light. 6.3. -
Page 9: Time Setting
7. Time setting 1. Under Time Setting menu, press “ ”/“ ” to select digit for adjustment. 2. Press “ ”/“ ” to increase or decrease the time value. 3. After setting, press “menu” to exit. 8. Measurement Cold spot Center spot Hot spot -The measured temperature at the pixel center is displayed at the upper left corner. -
Page 10: Color Palette
9. Color palette “Color palette” menu can change the representation color of the infrared image displayed on the screen or captured. A number of color palettes are available as below: 1. Gray-scale color: provides balanced linear color, help to reveal full details. High-contrast color: emphasize the displayed color, and the color contrast of high-temperature and low-temperature can therefore be improved. -
Page 11: Marking Of Spot Temperature
2. If turning off, it indicates that user can focus on the measured pixel per time. 12. Image mixing IR0002 can capture visible image of infrared image with the temperature distribution of target area clearly displayed on screen, resulting in a easier understanding of infrared image. -
Page 12: Image Capturing And Checking
13. Image capturing and checking 13.1. Image capturing 1. Press image capturing button and the symbol of “store photos yes no” will display on screen. 2. Press “MENU” to store image; press “SELECT” to delete the captured image. -If “NO SD” displayed at the lower left corner of screen, it indicates SD card is not installed. -
Page 13: Emissivity
14. Emissivity The emissivity of the surface of a material is its effectiveness in emitting energy as thermal radiation. The emissivity of the product can be adjusted from 0.10 to 1.00 with the default value of 0.95. Many common objects and materials (such as timber, water, skin and textile fabric) can reflect the heat energy effectively, so it is easy to obtain high accuracy.
