Microsensor MDM7000 Operation Manual page 31

MDM7000-GP/AP Smart Pressure Transmitter
Items Code
—
MDM7000-GP
—
MDM7000-AP
—
Application of hazardous area
1
2
4
A
B
C
E
F
G
J
K
L
0
T
Output signal H
Case S
P
Waterproof/explosion-proof connector
1
2
3
4
5
Note: Explosion-proof configuration applicable to PCEC/ATEX/IECEx standards Note:
Display N
L
R
—
Range
GP 2
3
4
5
6
7
AP 2
3
4
6
Description
Smart Gauge Pressure Transmitter
Smart Absolute Pressure Transmitter
China, Explosion-proof certification, No.CE23.6650
Ex db IIC T6~T4 Gb, GB/T3836.1-2021, GB/T3836.2-2021
China, Intrinsically safe certification, No.CE23.7688X
Ex ia IIC T4 Ga, GB/T3836.1-2021, GB/T3836.4-2021
China, Explosion-proof certification, Intrinsically safe certification
CSA, Explosion-proof certification
CSA, Intrinsically safe certification
CSA, Explosion-proof, Intrinsically safe certification
ATEX, Explosion-proof certification
ATEX, Intrinsically safe certification
ATEX, Explosion-proof, Intrinsically safe certification
IECEx, Explosion-proof certification
IECEx, Intrinsically safe certification
IECEx, Explosion-proof, Intrinsically safe certification
Non-hazardous area
Other certifications
4mA~20mA DC, HART
Stainless steel case with two outlet ports (F) M20×1.5
Aluminum alloy case with two outlet ports (F) M20×1.5
Specification
M20×1.5 waterproof connector, with plug
Non-explosion-proof adapter (F) M20×1.5, with plug 316 SS
Explosion-proof adapter (F) 1/2NPT, with plug
Explosion-proof adapter (F) M20×1.5, with plug
Non-explosion-proof adapter (F) G1/2, with plug
Without LCD display
Display module, -20℃ ~70℃
Display module, -40℃ ~60℃ (Please consult engineers for details)
Nominal range Minimum range
0.4bar 20mbar
2.5bar 125mbar
10bar 0.5bar
30bar 1.5bar
100bar 5bar
400bar 50bar
0.4bar 0.2bar
2.5bar 0.5bar
10bar 2bar
100bar 10bar
Material
PVC
316 SS
316 SS
316 SS
Upper (URL) Lower (LRL)
-0.4bar 0.4bar
-1bar 2.5bar
-1bar 10bar
-1bar 30bar
-1bar 100bar
-1bar 400bar
0bar 0.4bar
0bar 2.5bar
0bar 10bar
0bar 100bar
29
Applicable wire
IP rating
diameter
6mm~8mm IP67
6mm~8mm IP67
6mm~8mm IP67
6mm~8mm IP67
6mm~8mm IP67
Overload
10bar
40bar
60bar
150bar
200bar
800bar
10bar
40bar
60bar
200bar
