11 Naming

MDM7000-DP Smart Differential Pressure Transmitter
Items Code
—
MDM7000-DP
—
Application of hazardous area
1
2
4
A
B
C
E
F
G
J
K
L
0
T
Output signal H
Case S
P
Waterproof/explosion-proof connector
1
2
3
4
5
Note: Explosion-proof configuration applicable to PCEC/ATEX/IECEx standards Note:
Display N
L
R
—
Range
1
2
3
4
5
Description
Smart Differential Pressure Transmitter
China, Explosion-proof certification, No.CE23.6650
Ex db IIC T6~T4 Gb, GB/T3836.1-2021, GB/T3836.2-2021
China, Intrinsically safe certification, No.CE23.7688X
Ex ia IIC T4 Ga, GB/T3836.1-2021, GB/T3836.4-2021
China, Explosion-proof certification, Intrinsically safe certification
CSA, Explosion-proof certification
CSA, Intrinsically safe certification
CSA, Explosion-proof, Intrinsically safe certification
ATEX, Explosion-proof certification
ATEX, Intrinsically safe certification
ATEX, Explosion-proof, Intrinsically safe certification
IECEx, Explosion-proof certification
IECEx, Intrinsically safe certification
IECEx, Explosion-proof, Intrinsically safe certification
Non-hazardous area
Other certifications
4mA~20mA DC, HART
Stainless steel case with two outlet ports (F) M20×1.5
Aluminum alloy case with two outlet ports (F) M20×1.5
Specification
M20×1.5 waterproof connector, with plug
Non-explosion-proof adapter (F) M20×1.5, with plug 316 SS
Explosion-proof adapter (F) 1/2NPT, with plug
Explosion-proof adapter (F) M20×1.5, with plug
Non-explosion-proof adapter (F) G1/2, with plug
Without LCD display
Display module, -20℃ ~70℃
Display module, -40℃ ~60℃ (Please consult engineers for details)
Nominal range Minimum range
60mbar 2mbar
0.4bar 4mbar
2.5bar 25mbar
10bar 0.1bar
30bar 0.3bar
Material
PVC
316 SS
316 SS
316 SS
Upper (URL) Lower (LRL)
-60mbar 60mbar
-0.4bar 0.4bar
-2.5bar 2.5bar
-10bar 10bar
-30bar 30bar
26
Applicable wire
IP rating
diameter
6mm~8mm IP67
6mm~8mm IP67
6mm~8mm IP67
6mm~8mm IP67
6mm~8mm IP67
Static pressure One-sided high/low
range pressure overload
400bar 250bar
400bar 250bar
400bar 250bar
400bar 250bar
400bar 250bar
