Caution: Please read this manual carefully before operating
Damage caused by misuse is not covered by the warranty!
A compact and portable unit comprising a standard fog machine and 2 eye-popping light effects. The
400W fogger generates around 2500cu.ft/min, ample fog to easily fill smaller rooms and venues. The 9
bright RGB LEDs provide a traditional PAR wash effect and the additional central RGB moonflower then
adds colourful patterns which both combine with the fog to provide a complete room filling solution.
Control using either the in-built sound to light mode or with the included remotes, this all-in-one solution
is ideal for mobile DJs, house parties, small events and more.
•
Compact, portable unit comprising standard fog machine and 2 eye-popping light effects.
•
400W fog vaporizer with around 2500cu.ft/min output.
•
Nine 1W LEDs and a 2W moonflower LED add a bright colourful light show to the smoke effect.
•
Control using sound to light or with the included wired and RF remotes.
•
Supplied with UK and EU IEC leads and mounting bracket.
www.avsl.com
Compact LED Fog Machine with RGB Moonflower Effect
MoonCloud-400
Order ref: 160.491UK
User Manual
160.491UK Manual
Advertisement
Related Manuals for Qtx MoonCloud-400
Summary of Contents for Qtx MoonCloud-400
- Page 1 MoonCloud-400 Compact LED Fog Machine with RGB Moonflower Effect Order ref: 160.491UK User Manual Caution: Please read this manual carefully before operating Damage caused by misuse is not covered by the warranty! A compact and portable unit comprising a standard fog machine and 2 eye-popping light effects. The 400W fogger generates around 2500cu.ft/min, ample fog to easily fill smaller rooms and venues.
- Page 2 No user serviceable parts inside - do not open the case. Allow the unit to acclimatise to room temperature before operating. The MoonCloud-400 has a built-in fluid container so should be operated in an upright position. Ensure that the unit is positioned on a stable, non-slip surface.
- Page 3 Operation: Wired Control Unit: The wired control unit supplied with the MoonCloud-400 must be connected at all times during use. Once the unit is warm enough to produce fog, the red LED at the bottom of the unit will light up.
- Page 4 Specifications: Power supply 220-240Vac, 50/60Hz (IEC) Power consumption 400W Fuse rating Warm up time 3-5 minutes Remote control frequency 433Mhz Fog output (approx.) 2500 cu.ft per minute Fluid capacity 0.3 litre LED power 1W RGB LED x 9pcs + 2W RGB moonflower LED Battery remote 23A 12V (not supplied) Dimensions...
