CHANGING THE COLDPLATE
Non-Abrasive
Cloth
IHS
STEP 1
STEP 2
STEP 1
Cleaning the CPU: Wipe the CPU's contact surface with a non-
abrasive cloth or Q-tip.
STEP 2
Applying Thermal Compound: Apply the enclosed thermal
grease (thermal compound) on the CPU heat spreader (IHS) as
shown in the image.
There is no need to cover the whole IHS – applying too much thermal
grease will have a negative impact on the cooling performance!
- 7 -
