Endless Pools
Hydrostride
®
Warnings and Safety Information . . . . . . . . . . . . . . . . . . . . 1
Endless Pools Hydrostride Overview . . . . . . . . . . . . . . . . . 5
Choosing a Location . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Receiving the Hydrostride . . . . . . . . . . . . . . . . . . . . . . . . . 7
- Gunite Pool . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
- Gunite Pool With Vinyl Liner . . . . . . . . . . . . . . . . . . . . 20
- Steel Panel Pool With Vinyl Liner . . . . . . . . . . . . . . . . . 31
Junction Box . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
Hydrostride Assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
Section 1:
GENERAL OVERVIEW OF ENDLESS POOLS HYDROSTRIDE
The Endless Pools Hydrostride is an underwater hydraulically driven treadmill that adds a smooth and adjustable workout to
any conventional pool under new construction. Research shows that, compared to land-based treadmills, underwater tread-
mills allow the end user to burn more calories, enjoy an increased range of motion, and suffer less joint impact.
The Hydrostride attaches directly to the pool wall with the use of a wall mounting bracket. Two hydraulic hoses carrying a
non-food grade, biodegradable hydraulic fluid run between the Hydrostride and remotely located hydraulic power unit, thus
eliminating the need for electricity poolside. The hydraulic hoses that carry the fluid from the power unit to the Hydrostride
are hidden in the pool wall and under the pool deck. Because the wall mounting bracket is embedded in the pool wall, the
Hydrostride is ideal for new pool construction or pool refurbishment.
The Hydrostride features a spacious 18-3/4" (48cm) wide belt for walking or running. With its 5-HP motor, the Hydrostride
reaches a top speed of 5.5 mph. The Hydrostride is activated using a water-resistant remote control that turns the unit on and
off and adjusts the speed. The Endless Pools Fastlane
Hydrostride to add intensity to the workout.
The Hydrostride can be installed in multiple ways:
If installing in a traditional gunite pool, the Hydrostride can sit above the pool floor as shown in Figure 1.1 or can be recessed
so that the unit sits flush with the pool floor as shown in Figure 1.2.
Fig. 1.1
5
Installation
™
- Gunite Pool . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
- Gunite/Steel Panel Pool With Vinyl Liner . . . . . . . . . . . 48
Installation Of The Hydraulic Power Unit . . . . . . . . . . . . 52
Electrical Requirements For The UK (50HZ) . . . . . . . . . 55
Equipment Start Up . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56
Using The Hydrostride . . . . . . . . . . . . . . . . . . . . . . . . . . . 57
Bonding The Hydrostride . . . . . . . . . . . . . . . . . . . . . . . . . 58
Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60
(swim current) can also be installed and used in conjunction with the
®
Fig. 1.2
