Uplift Desk ACC095 Manual

Adjustable Tablet Stand
ACC095

Package Contents

Clamp Arm

Step 1 - Base Attachment

A. Align the holes in the bottom of the Arm with
the holes in the Base, with the countersunk
holes for the screw heads on the opposite
side of where the Arm will attach.
B. Loosely insert the M5x10 Screws through the
bottom of the Base and into the Arm.
C. Once both screws have been started, tighten
them with the Smaller Allen Wrench (3mm).
Step 2 - Clamp Attachment -
Ball and Socket Joint
A. Remove the knob from the back of the
Clamp by rotating it counterclockwise.
B. Place the knob over the ball on the upper
end of the Arm.
C. Fit the threaded socket on the back of
the Clamp over the ball.
D. Rotate the knob clockwise to secure
the Clamp to the Arm's ball.
Step 3 - Clamping Your
Device
A. The Clamp has a range of 5" to 8.9"
and is spring-loaded to hold your
device. Grasp each end of the Clamp
and pull outward.
B. Place your device between the ends of
the Clamp and gently allow the ends
to spring closed, gripping your device.
1
Base M5x10 Screws
qty 2
Smaller Allen Wrench (3mm) Larger Allen Wrench (5mm)
