  • Page 1 Porsche Mobile Charger Good to know – Owner’s Manual...
  • Page 2 Dr. Ing. h.c. F. Porsche AG Porsche is fitted with any equipment not described Germany Vertrieb Customer Relations in this manual, your authorized Porsche dealer will be Porscheplatz 1 glad to provide information regarding correct opera- Operating instructions tion and care of the items concerned.
  • Page 3 You can access the comprehensive Owner's Manual Possible serious injury or WARNING at the following web address: death https://tinyurl.com/porsche-e-help Failure to observe warning notes in the “Warning” category may result in serious injury or death. Possible moderate or CAUTION slight injury Failure to observe warning notes in the “Caution”...

  • Page 4: Table Of Contents

    Table of Contents To the Operating instructions Pictogram Explanation......3 Safety Safety instructions....... 4 Intended Use.

  • Page 5: To The Operating Instructions Pictogram Explanation

    To the Operating instructions To the Operating instructions There is a risk of electric shock due Pictogram Explanation to incorrect use. Depending on the country, various pictograms may be depicted on the charger. Observe the associated Owner’s The charger may only be used when the Manual, particularly the warning and temperature lies between –30 °C and safety instructions.

  • Page 6: Safety

    Further information is available from your au- Never immerse the charger or plugs in water or thorized Porsche dealer or your local electricity supplier. spray them directly with water (e.g. high-pres- sure cleaning equipment or garden hoses).
  • Page 7 (FCC). aux rayonnements IC établies pour un environnement Porsche recommends having the electrical in- non contrôlé. Cet équipement doit être installé et Ces limites sont conçues pour assurer une protection stallations used for charging checked regularly utilisé...

  • Page 8: Intended Use

    Includes Includes Overview charger commissioned by a qualified electrician and set the charging current limit suited to the Charger control unit home installation. g Refer to chapter “Charging Current Limit“ on page 14. Intended Use Charger with integrated control and protection de- vice for charging mode 2 to charge vehicles with a high-voltage battery that comply with the generally accepted standards and directives governing electric...

  • Page 9: Requirements And Prerequisites

    Requirements and prerequisites g Refer to chapter “Operating unit status indicators Mounting – Do not install the Basic wall mount in stables, and error messages“ on page 16. livestock buildings or locations where ammonia Installing the wall bracket gases occur. Requirements and prerequi- –...
  • Page 10 Mounting Installing the plug holder Inserting the control unit in the wall mount Fig. 5: Drilling dimensions Fig. 4: Distance from wall mount to plug holder 1. Remove plug holder 1 from the cover (Fig. 5) 2 (Fig. 5). Fig. 6: Inserting control unit When installing the plug holder, ensure a distance of 2.

  • Page 11: Set Up

    Set up Set up Vehicle charging and supply cables Vehicle charging cable and connector information Depending on the country equipment, different vehi- cle charging connectors A and vehicle charging plugs B are supplied. IEC 62196-2/ SAE-J1772-2009 Type 1 Power cable selection For regular charging with optimal charging speed, use only the following power cables.
  • Page 12 125 V branch circuit rated not less than sionally. 20 A. Porsche recommends home owners only install in- dustrial-quality electrical receptacles and have the IEC 60309-2 NEMA 5-15 installation performed by qualified electricians in ac-...
  • Page 13 This is normal and not an indication of a defect in receptacle use or improper installation are not an in- the charger. Observe the operating instructions dication of a defect in the vehicle or Porsche charg- provided with the charger, particularly the warn- ing hardware.
  • Page 14 Fur- ther information is available from your authorized Avoid direct contact between the charging Porsche dealer. equipment and rain. Use a rainproof NEMA 3R housing. 1. Time of printing. Further information is available from your authorized Porsche dealer.

  • Page 15: Operating

    5. Pull out the plug B fully. Check with your Porsche Partner or the local Operating instructions electric utility. NOTE Risk of damage to the charger 1. Status of printout. Check with your Porsche Partner.

  • Page 16: Charging

    Further 3. Charging starts automatically. For information on connecting and disconnecting the information is available from your authorized Porsche �� The light indicator of the On/Off button vehicle cable to and from the vehicle charge port and dealer.
  • Page 17 Operating Deactivating and activating ground Release the buttons after the control unit light indicator has flashed six times. wire monitoring 2. After 1 second, press the On/Off and Reset Electric shock, short cir- DANGER buttons again. cuit, fire, explosion Release the buttons after the control unit light Using the charger without active ground wire moni- indicator has flashed six times.

  • Page 18: Operating Unit Status Indicators And Error Messages

    Operating unit status indicators and error messages Operating unit status indicators and error messages Indicator light Meaning Remedial action On/Off lights up green. The charger is ready but not charging. Start the charging process. g Refer to chapter “Starting charging“ on page 14. Power supply/home connection is off.
  • Page 19 Only charging with reduced power until cooled. Vehicle is off. If the error persists, have the operator control unit Operator control unit lights up yellow. checked by a qualified dealer/Porsche Partner. Reset is off. On/off lights up red. The power plug is overheated.
  • Page 20 Power supply/home connection is off. The charging process is interrupted. If the error persists, have the vehicle checked by a quali- Vehicle flashes yellow. fied dealer/Porsche Partner. Operator control unit is off. Reset is off. On/off lights up red. The power supply or vehicle cable is faulty.
  • Page 21 15. Reset is off. Only grounded power grids: Have the operator control unit checked by a qualified dealer/Porsche partner and the power grid/home connection by an electrician. On/off lights up red. The indicator light for the operator control Have the operator control unit replaced by a qualified unit Reset button is faulty.
  • Page 22 Power supply/home connection lights up red. If the error persists, have the operator control unit The charging process is interrupted. checked by a qualified dealer/Porsche Partner and the The vehicle lights up red. power supply/home connection by an electrician. Operator control unit lights up red.

  • Page 23: Transport

    Hook bag to the front and rear tie-down rings. teries in accordance with the applicable environ- mental regulations. Cleaning and maintenance If you have any questions about disposal, please Check the charger regularly for damage and dirt and contact a Porsche Partner . clean if necessary.

  • Page 24: Technical Data

    Technical data Technical data Electrical data 9Y0.971.675… MCB36U1 x MCB96U1 x Power 3.6 kW 9.6 kW Rated current 16 A, 1-phase 40 A, 1-phase Power supply voltage 120 V – 240 V, 120 V to ground 120 V – 240 V, 120 V to ground Power frequency 50 Hz/60 Hz 50 Hz/60 Hz...
  • Page 25 Technical data Mechanical data Control unit weight 5.3 – 7.7 lbs (2.4 – 3.5 kg) Wall bracket dimensions 5.4 in (136 mm) x 15.4 in (391 mm) x 3.0 in (76 mm) (width x height x depth) Wall bracket weight approx.

  • Page 26: Type Plate

    If you have questions about the reg- ular electrical inspection of the charg- ing infrastructure (e.g. VDE 0702) please visit https://www.porsche.com/international/ac- cessoriesandservice/porscheservice/vehicleinforma- tion/documents/ or contact a Porsche Partner. Fig. 11: Type plate (example) Brazil Product name Article number Power and rated current...

  • Page 27: Index

    Index Index Industrial electrical sockets..... 10 Installing the plug holder......8 Technical data.
