- Page 1 E10SP Motor Safety, Operation, Maintenance & Parts Manual LT15 rev. E2.00 - E8.13 LT15W rev. A1.00 - A1.14 Safety is our #1 concern! Read and understand all safety information and instructions before oper- ating, setting up or maintaining this machine.
- Page 2 Printed in the United States of America, all rights reserved. No part of this manual may be reproduced in any form by any photographic, electronic, mechanical or other means or used in any information storage and retrieval system without written permission from Wood-Mizer 8180 West 10th Street Indianapolis, Indiana 46214...
-
Page 3: Table Of Contents
Table of Contents Section-Page SECTION 1 ABOUT THIS MANUAL SECTION 2 OPERATION Starting The Motor .................2-1 SECTION 3 MAINTENANCE Safety......................3-1 SECTION 4 REPLACEMENT PARTS Motor Starter Assembly .................4-1 LT15 Rev. E6.06+ Motor Starter Assembly .................4-3 LT15 Rev. E2.00 - E6.05 Motor Assembly ..................4-5 Throttle/Clutch Assembly ..............4-6 LT15 E10... -
Page 4: About This Manual
SECTION 1 ABOUT THIS MANUAL This manual is provided as a supplement to the equipment manufacturer’s manuals. This manual provides information specific to the use of this equipment on the Wood-Mizer ® sawmill. Refer to the sawmill operator’s manual and manufacturer's manual before attempting to operate this equipment. -
Page 5: Operation
Operation Starting The Motor SECTION 2 OPERATION Starting The Motor DANGER! Ensure the blade is disengaged and all persons are out of the path of the blade before starting. Failure to do so will result in death or serious injury. Turn the main switch on the starter box to the ON position. -
Page 6: Maintenance
Maintenance Safety SECTION 3 MAINTENANCE Refer to the manufacturer’s manual for maintenance intervals and procedures unless oth- erwise instructed in this manual. Follow the manufacturer’s recommendations for dusty conditions. IMPORTANT! This manual only provides information about additional procedures or procedures to be performed at different time intervals than found in the manufacturer's manuals. - Page 7 Maintenance Safety This symbol identifies the interval (hours of operation) at which each maintenance pro- cedure should be performed. "AR" signifies maintenance procedures which should be performed as required. Maintenance WMdoc072619...
-
Page 8: Replacement Parts
Disconnect and lock out power supply before servicing! Keep all electrical component covers closed and securely fastened during machine operation. Failure to do so will result in severe personal injury. Wood-Mizer Products, Inc. 800-525-8100 Reorder #S20061 150178-1 E10SP01doc072619 Replacement Parts... - Page 9 E10S Replacement Parts Motor Starter Assembly DESCRIPTION ( Indicates Parts Available In Assemblies Only) PART # QTY. MOTOR MODULE, 10HP 1-PHASE 208-230V ELECTRIC MOTOR 036216 Motor Parts (See Section 4.3) Control Assembly, LT15 E10 1-Phase 230V 053702 Bolt, 5/16-18 x 3/4 Hex Head F05006-5 Bracket, Front Electric Motor Mount 035991...
-
Page 10: Motor Starter Assembly
E10S Replacement Parts Motor Starter Assembly Motor Starter Assembly LT15 Rev. E2.00 - E6.05 150112-1 DESCRIPTION ( Indicates Parts Available In Assemblies Only) PART # QTY. MOTOR MODULE, 10HP 1-PHASE 208-230V ELECTRIC MOTOR 036216 Motor Parts (See Section 4.3) Control Assembly, LT15 240V 1P Start/Stop 050984 Bolt, 5/16-18 x 3/4 Hex Head F05006-5... - Page 11 E10S Replacement Parts Motor Starter Assembly Bracket, Rear Electric Motor Mount 035992 Box, 1-Phase Electric Motor 035990 Fuse, 1A 600V Class CC 051286 Fuse, 4A 250V 1/4 x 1-1/4 Glass MDL Delay 051285 Disconnect, 100A 3Ph Non_fused 050906-1 Breaker, 60A 2P QUO260 050944 Contactor, 65A 3P 1NO 1NC 24VAC 050930...
-
Page 12: Motor Assembly
E10S Replacement Parts Motor Assembly Motor Assembly Motor Direction 150109-1 DESCRIPTION ( Indicates Parts Available In Assemblies Only) PART # QTY. COVER, ENGINE P12393 MOTOR ASSEMBLY, LT15 10HP 1-PHASE 036215 Motor, 10HP 1-phase Lincoln 60Hz 036214 Bushing, 1 3/8 Split Taper P04864 Sheave, BK45QT 036057... -
Page 13: Throttle/Clutch Assembly
E10S Replacement Parts Throttle/Clutch Assembly Throttle/Clutch Assembly LT15 E10 Rev. E1.00+ 150111G 16 17 DESCRIPTION ( Indicates Parts Available In Assemblies Only) PART # QTY. KNOB, 5/8-11 BALL P04211 HANDLE, LT15 CLUTCH 016487 BUSHING, 5/8 ID X 7/8 OD X 1 1/8 LONG FL BRONZE 016486 COLLAR, 5/8 ID LOCK P05035... - Page 14 E10S Replacement Parts Throttle/Clutch Assembly Bolt, 3/8-16 x 2 Hex Head Gr5 F05007-124 Nut, 3/8-16 Hex Nylon Lock F05010-10 Block, LT15 Brake 016488 Screw, 10-24 x 1 Socket Head F05004-2 Nut, #10-24 Keps F05010-14 Idler, 4" O.D. x 3/8 Bore 034602 Bolt, 3/8-16 x 2-3/4”...
-
Page 15: Index
INDEX maintenance parts list motor assembly motor starter assembly 4-1, 4-3 throttle/clutch starting Index E10SP01doc072619...
