LMU-5541 Hardware & Installation Guide
LMU-5541™
Hardware and Installation Guide
IMPORTANT: DO NOT INSTALL OR USE THE SOFTWARE OR
DOCUMENTATION UNTIL YOU HAVE READ AND AGREED TO
THE
LICENSE AGREEMENT
WARRANTY
AND
REGULATORY
1 Introduction
Welcome to the LMU-5541™ Hardware and Installation Guide. This manual is intended
to give you information on the basic setup and installation of the CalAmp LMU-5541™
product(s) including hardware descriptions, environmental specifications, wireless
network overviews and device installation.
1.1 About This Manual
The LMU-5541™ is one of the most flexible economy mobile tracking hardware
products available. In order to accurately describe the functionality of these units
we have broken this manual into the following sections:
System Overview - A basic description of a CalAmp LMU-5541™
based tracking system. This includes a description of roles and
responsibilities of each of the CalAmp components as well as a brief
overview of the wireless data technologies used by the LMU-5541™.
Hardware Overview - Describes the physical characteristics and
interfaces of the LMU-5541™.
Installation and Verification - Provides guidance for the installation
of the LMU-5541™ in a vehicle and instructions on how to verify the
installation is performing adequately.
1.2 About The Reader
In order to limit the size and scope of this manual, the following assumptions have
been made about the reader.
You are familiar with GPS concepts and terminology
You have some experience with installing equipment in vehicles
You are familiar with the use of AT Commands
You are familiar with the use of terminal programs such as
HyperTerminal or PuTTY
1.3 About CalAmp
CalAmp is a leading provider of wireless communications products that enable
anytime/anywhere access to critical information, data and entertainment content.
With comprehensive capabilities ranging from product design and development
through volume production, CalAmp delivers cost-effective high quality solutions
to a broad array of customers and end markets. The Company also provides
wireless data communication solutions for the telemetry and asset tracking
markets, private wireless networks, public safety communications and critical
infrastructure and process control applications. For additional information, please
visit the Company's website at www.calamp.com.
https://puls.calamp.com/wiki/LMU-5541_Hardware_%26_Installation_Guide
AND REVIEWED THE
LIMITED
INFORMATION.
LMU-5541 Hardware & Installation Guide - PULS Wiki
Contents
1 Introduction
1.1 About This Manual
1.2 About The Reader
1.3 About CalAmp
1/29

Advertisement

Table of Contents
loading

Related Manuals for CalAmp LMU-5541

Summary of Contents for CalAmp LMU-5541

  • Page 1: Table Of Contents

    Welcome to the LMU-5541™ Hardware and Installation Guide. This manual is intended 4.2 I/O Connector to give you information on the basic setup and installation of the CalAmp LMU-5541™ 4.3 Serial Interface Connectors product(s) including hardware descriptions, environmental specifications, wireless 4.4 Serial Interface Cables &...

  • Page 2: About The Calamp Location Messaging Unit-Lmu-5541

    ETA, monitoring vehicle and driver status or dispatching the vehicle to its next pick up. These functions, of course, are completely dependent on the capabilities of the vehicle management application. The role of the CalAmp LMU-5541™ is to deliver the location information when and where it is needed.

  • Page 3: Component Descriptions

    In some cases, it is necessary to run an application in the vehicle while it is being tracked by the backend software. Such examples could include instant messaging between vehicles or a central office, in-vehicle mapping or driving directions, email or database access. In most of these cases you will be using the LMU-5541™...

  • Page 4: Battery Back-Up Devices

    Storage and Shipping One potential source of EOS is proximity of one LMU-5541™ GPS Antenna to another LMU-5541™ GSM Antenna. Should one of the units be in a transmit mode the potential exists for the other unit to become damaged. Therefore any LMU-5541™ GPS Antenna should be kept at least four inches apart from any active LMU- 5541™...
  • Page 5 EMC compliant for a ground vehicle environment SAE Test: SAE J1113 Parts 2, 12, 21 and 41 Operating Voltage Range The LMU-5541™ supports vehicles with 12 or 24 VDC systems including transients and electrical system noise; this includes ranges from 8 to 32 VDC. Electrostatic Discharge (ESD) No damage or performance degradation after the ESD disturbance.

  • Page 6: Lmu-5541™Connectors

    Serial 5 Pin Molex (switch power TTL Levels) Power, Ignition, I/O 4-Pin Molex I/O connector 22-Pin Molex 4.1 Power Connector The LMU-5541™ uses a 4 pin Molex 43045-0402 connector as its power connection. The pin out is as follows: Signal Name Description...

  • Page 7: I/O Connector

    LMU-5541™ Header (looking into LMU) 4.3 Serial Interface Connectors The LMU-5541™ offers 2 serial interface connections (Host/Aux1 and DB-9 SerialAux 2) on its front face. Host/AUX1 is provided via a Molex 43650-0501 connector using the following pin out: Signal Name...

  • Page 8: Accessories

    The Serial Combo Adapter is designed to allow laptops, MDTs, barcode readers and other devices to communicate with the LMU-5541™ via a direct serial connection. While using this cable, the LMU-5541™ will accept AT Commands and act as a modem. No setup of the LMU-5541™ is necessary to use this cable. The 133564-1 also has switched power capabilities which allow for power to the serial device to be regulated.

  • Page 9: Ignition And Inputs

    4.7.1 Ignition and Inputs The LMU-5541™ provides up to 7 High/low selectable inputs and one Ignition Sense input.. These inputs are protected from typical vehicle transients and can be directly connected to most vehicle level logical inputs from 4 volts up to the vehicle power input level (typically 12 VDC). Their input impedance is approximately 10k .

  • Page 10: Led Outputs

    100ohm series resistor. When off, these outputs are high impedance 4.7.4 Status LEDs The LMU-5541™ is equipped with five Status LEDs; Power, BT, WiFi, GPS, COMM (wireless network). The LEDs use the following blink patterns to indicate service:...

  • Page 11: Configuration And Activation

    5 Configuration and Activation This section details how to quickly get an LMU-5541™ provisioned and configured to point at a specific server. It is assumed that a PEG script has already been created and is being managed through LMU Manager or PULS™, the CalAmp Maintenance System.

  • Page 12: Auto Provisioning Of Apns In Lmu

    9/28/23, 4:30 PM LMU-5541 Hardware & Installation Guide - PULS Wiki 2. From the handset, send an SMS message to the LMU-5541™ phone number: RP,2319,0,ddd.ddd.ddd.ddd RP,768,0,ddd.ddd.ddd.ddd (32-bit products only) RP,769,0,ppppp Where ddd.ddd.ddd.ddd is the publicly addressable IPV4 address of your LM Direct™ server and ppppp is the UDP port number 3.

  • Page 13: Activating Lmu Using At Commands

    5.3 Activating LMU using AT Commands Check with the CalAmp Sales team for availability of the LMU-5541™ with LTE, GSM or HSPA operators around the world. The operator will provide you with a SIM for each account activated. If they are especially nice (or you are especially persistent) they will also give you a list tying the IMSI (International Subscriber Identifier) of the SIM to the phone number assigned to it.

  • Page 14: Installing The Lmu

    9/28/23, 4:30 PM LMU-5541 Hardware & Installation Guide - PULS Wiki AT$APP PARAM 2306,0,“” (for a blank APN) Only enter this next command if you have been given a non-zero PIN as any errors may lock you out of the modem.

  • Page 15: Plan The Installation

    LMU may void the warranty. See the LMU Environmental Specifications for the exact measurements and specifications of the LMU-5541™. Typical installations will place the LMU under the vehicle dash board, or in the trunk. Make sure you can get access to the unit afterwards as under some circumstances it may be necessary to add additional wiring or connections to the LMU.

  • Page 16: Access To The Sim (Subscriber Identity Module) Card

    You may find it useful to be able to view the LEDs periodically to make sure that the LMU is operating properly. If at any time you should encounter a problem with the LMU, you may need to read the LEDs in order to troubleshoot the problem. If you cannot fix the LMU yourself, you will need to provide the LED information to CalAmp customer support.

  • Page 17: Place The Lmu In The Vehicle

    9/28/23, 4:30 PM LMU-5541 Hardware & Installation Guide - PULS Wiki Be sure to consider the design decisions described in the previous sections. When you are ready to begin installing the LMU, follow these steps: 6.3.1 Place the LMU in the Vehicle Typically, the LMU should be placed under the passenger seat or dashboard of the vehicle.

  • Page 18: Installation Verification

    Note that these processes are all based on issuing AT Commands to the LMU-5541™. It is expected that installers will have access to a serial port expansion cable and a laptop or PDA capable of a terminal connection. Alternatively, an SMS message can be sent to an LMU-5541™ to obtain its current status.

  • Page 19: Inbound Verification

    6.4.3 Inbound Verification The last item to verify is that the LMU-5541™ is sending data to the correct server. In general, this is a two-step process that will need the aid of an observer on the back end. That is, a technician will have to be logged in so they can monitor data coming into the backend mapping/vehicle management application.
  • Page 20 9/28/23, 4:30 PM LMU-5541 Hardware & Installation Guide - PULS Wiki <App ID>: <p style="margin-left: 40px;">The Application ID value of the LMU indicating the host platform and the wireless networking technology of the LMU. <Firmware Version>: The current firmware version in use by the LMU COM: <RSSI>:...

  • Page 21: Lmu-Lmu5541 Router Configuration & Management

    9/28/23, 4:30 PM LMU-5541 Hardware & Installation Guide - PULS Wiki This is the current UDP port the LMU will use to deliver its LM Direct™ data. This value should match UDP port you are using on your LM Direct™ server. It is typically 20500.
  • Page 22 9/28/23, 4:30 PM LMU-5541 Hardware & Installation Guide - PULS Wiki Enter Password: SB327 compliant password. Please reachout to your FAE for details Once you log in you will see the Overview screen: https://puls.calamp.com/wiki/LMU-5541_Hardware_%26_Installation_Guide 22/29...

  • Page 23: How To Turn On Wifi

    9/28/23, 4:30 PM LMU-5541 Hardware & Installation Guide - PULS Wiki 7.4 How to turn on WIFI To start the WIFI interface you can simply run the following PEG command: Note: By default the WIFI interface is configured in Access Point mode with no security.

  • Page 24: How To Test Wifi Connectivity

    As we mentioned, WIFI on the LMU5541 default is in access point mode so all clients can join it and get an IP address. If you run WIFI on the LMU5541 from your Windows or Linux machine with WIFI enabled, you should see a new WIFI device with "calamp" as the SSID.

  • Page 25: Toggle Between Access Point And Client Mode

    Connect the mini USB to the LMU-5541™ and connect the other end to a USB slot on your computer. Connect 4-pin power harness SC5888 to the power connector on the LMU-5541™. Connect the wires of the power harness to +12VDC power supply; RED +12VDC, WHT +12VDC (ignition), BLK Ground https://puls.calamp.com/wiki/LMU-5541_Hardware_%26_Installation_Guide...

  • Page 26: Maintenance Computer Network Setup

    9/28/23, 4:30 PM LMU-5541 Hardware & Installation Guide - PULS Wiki Take an Ethernet cable and connect one end to the LMU-5541™ RJ-45 connector and the other end to the maintenance computer. Launch the terminal emulation program. Power up the LMU-5541™.

  • Page 27: Usb Driver Installation

    9/28/23, 4:30 PM LMU-5541 Hardware & Installation Guide - PULS Wiki When completed, “LMU5541-Boot >” will appear. NAND erase.chip: device 0 whole chip Erasing at 0x1ffe0000 -- 100% complete. LMU5541-Boot > 8.5 USB driver installation If the USB driver has been previously installed, skip the USB driver installation.

  • Page 28: Programming The Co-Processor

    Enter Password: SB327 Compliant Password. Please reachout to your FAE for details Click on Login A new WinSCP screen will appear. On the left side, browse for C:\tftpboot The right half should be pointed to the /root directory in the LMU-5541. https://puls.calamp.com/wiki/LMU-5541_Hardware_%26_Installation_Guide 28/29...
  • Page 29 9/28/23, 4:30 PM LMU-5541 Hardware & Installation Guide - PULS Wiki Transfer the file called LMU7030-CoProc_vX.X.bin via SCP over to root. Drag the file LMU7030-vX.X.bin across the screen to the root side. On the Terminal Emulation screen, press <Enter> to bring up the LMU5541 login: Username: root Password: SB327 Compliant Password.
