CalAmp Viper SC+ Quick Start Manual

Package Contents (Basic Unit)
If you ordered Viper SC+ part number:
US & Canada
140-5018-502 VHF 136-174 MHz, 6.25-50 kHz BW, Viper SC+ Basic Unit
140-5018-503 VHF 136-174 MHz, 6.25-50 kHz BW, Viper SC+ Basic Unit - Dual RF Port
140-5028-504 200 215-240 MHz, 6.25-100 kHz BW, Viper SC+ Basic Unit
140-5028-505 200 215-240 MHz, 6.25-100 kHz BW, Viper SC+ Basic Unit - Dual RF Port
140-5048-302 UHF 406.1125-470 MHz, 6.25-50 kHz BW, Viper SC+ Basic Unit
140-5048-303 UHF 406.1125-470 MHz, 6.25-50 kHz BW, Viper SC+ Basic Unit - Dual RF Port
140-5048-502 UHF 450-512 MHz, 6.25-50 kHz BW, Viper SC+ Basic Unit
140-5048-503 UHF 450-512 MHz, 6.25-50 kHz BW, Viper SC+ Basic Unit - Dual RF Port
140-5098-304 900 880-902 MHz, 12.5-100 kHz BW, Viper SC+ Basic Unit
140-5098-305 900 880-902 MHz, 12.5-100 kHz BW, Viper SC+ Basic Unit - Dual RF Port
140-5098-504 900 928-960 MHz, 12.5-100 kHz BW, Viper SC+ Basic Unit
140-5098-505 900 928-960 MHz, 12.5-100 kHz BW, Viper SC+ Basic Unit - Dual RF Port
ETSI/AS/NZ Compliant (All units ETSI/AS/NZ)
140-5018-600 VHF 142-174 MHz, 12.5-25 kHz BW, Viper SC+ Basic Unit
140-5018-601 VHF 142-174 MHz, 12.5-25 kHz BW, Viper SC+ Basic Unit - Dual RF Port
140-5048-400 UHF 406.1125-470 MHz, 12.5-25 kHz BW, Viper SC+ Basic Unit
140-5048-401 UHF 406.1125-470 MHz, 12.5-25 kHz BW, Viper SC+ Basic Unit - Dual RF Port
140-5048-600 UHF 450-512 MHz, 12.5-25 kHz BW, Viper SC+ Basic Unit
140-5048-601 UHF 450-512 MHz, 12.5-25 kHz BW, Viper SC+ Basic Unit - Dual RF Port
Your package contains:
(1) Viper SC+ IP Router

(1) 60 in. CAT-5 Ethernet Cable

(1) Power Cable

(1) Start Up CD-ROM and Product Documentation Card

Viper SC+ Developer Kits (2 Piece Kit)
If you ordered Viper SC+ part number:
250-5018-500 VHF 136-174 MHz Viper SC+ Developer's Kit (2 Vipers)
250-5028-502 200 215-240 MHz Viper SC+ Developer's Kit (2 Vipers)
250-5048-300 UHF 406.1125-470 MHz Viper SC+ Developer's Kit (2 Vipers)
250-5048-500 UHF 450-512 MHz Viper SC+ Developer's Kit (2 Vipers)
250-5098-300 900 880-902 MHz Viper SC+ Developer's Kit (2 Vipers)
250-5098-500 900 928-960 MHz Viper SC+ Developer's Kit (2 Vipers)
Your package contains:
(2) Viper SC+ Basic Units

(2) SMA-Male to BNC-Female Connectors

(2) SMA Female to BNC-Male Connectors

(2) TNC-Male to BNC-Female Connectors

(2) Mini Circuits 5 W 20 dB Attenuators

(2) Flex Rubber Duck Antennas (VHF, UHF, or 900 MHz)

(2) 120 V AC to 13.8 V DC 4 Amp Power Supply

Viper SC+ Developer Kits (3 Piece Kit)
If you ordered Viper SC+ part number:
250-5018-510 VHF 136-174 MHz Viper SC+ Developer's Kit (3 Vipers)
250-5028-512 200 215-240 MHz Viper SC+ Developer's Kit (3 Vipers)
250-5048-310 UHF 406.1125-470 MHz Viper SC+ Developer's Kit (3 Vipers)
250-5048-510 UHF 450-512 MHz Viper SC+ Developer's Kit (3 Vipers)
250-5098-310 900 880-902 MHz Viper SC+ Developer's Kit (3 Vipers)
250-5098-510 900 928-960 MHz Viper SC+ Developer's Kit (3 Vipers)
Your package contains:
(3) Viper SC+ Basic Units

(3) SMA-Male to BNC-Female Connectors

(3) SMA Female to BNC-Male Connectors

(3) TNC-Male to BNC-Female Connectors

(3) Mini Circuits 5 W 20 dB Attenuators

(3) Flex Rubber Duck Antennas (VHF, UHF, or 900 MHz)

(3) 120 V AC to 13.8 V DC 4 Amp Power Supply

Kit Components
Description Item
Viper SC+ IP Router
60 in. Cat 5 Ethernet Cable
Power Cable
SMA Male to BNC Female
Connector
SMA Female to BNC Male
Connector
TNC Male to BNC Female
Connector
Mini Circuits 5 W 20 dB
Attenuator
Flex Rubber Duck Antenna
(VHF, UHF, or 900 MHz)
120 VAC to 13.8 VDC
4 A Power Supply
Product Documentation
http://help.calamp.com/files/references/manuals/Viper_SC_User_Manual.pdf
Any changes or modifications not expressly approved by the party responsible for compliance (in the country
where used) could void the user's authority to operate the equipment.
CalAmp reserves the right to update its products, software, or documentation without obligation to notify any
individual or entity. Product updates may result in differences between the information provided and the
product shipped. For access to the most current product documentation and application notes, visit
www.calamp.com.
Quick Start Guide
Viper SC+
™
INTELLIGENT IP ROUTER FOR LICENSED SPECTRUM
© 2010-2013 CalAmp
PN 004-5008-000 Rev. B
Revised: March 2014
