Summary of Contents for TW Audio CBQ30
- Page 1 Assembly CBQ30 Instructions...
- Page 2 Thank you for choosing a high-quality product “MADE IN GERMANY” from the brand TW AUDiO. The cradle bar for flying CBQ30 is an accessory for the VERA S30 loudspeaker. It is characterized by a subtle look, a remarkable size to weight ratio and ease of use.
- Page 3 Assembly Instructions CBQ30 Notes on the products Before using the device, carefully read the assembly instructions and keep it with the Read manual CBQ30 cradle bar for flying . before use! General information Assembly instructions: OM-CBQ30 Version 2.0 en, 07/2022 ©...
-
Page 4: Table Of Contents
Setup ........................9 Wind load ........................ 9 System setup CBQ30 to VERA S30 loudspeaker ........... 10 System setup CBQ30 to VERA S30 loudspeaker - cardioid mode ......12 5. Transport and storage ....................14 6. CE Conformity Declaration .................... 15... -
Page 5: Safety | Intended Use
Note the operating modes described in this assembly instructions. Other uses are not per- missible. Damage caused by improper use is not covered by TWAMBO. Before every operation, check the scope of delivery of the CBQ30 cradle bar for flying for its completeness and ensure that all parts are in perfect condition. WARNING The CBQ30 cradle bar for flying may only used with the VERA S30 loudspeaker. - Page 6 When working with heavy loads exceeding 20 kg (44 lbs.), use suitable aids (dollies, hoisting slings, etc.). Multiple persons may be required depending on the situation. NOTE The payload of the CBQ30 cradle bar for flying is designed of not more than six VERA S30 loudspeaker. Do not exceed this payload. WARNING Check the Double Stud connections each time you install the CBQ30 cradle bar for flying.
-
Page 7: Overview
Assembly Instructions CBQ30 2. Overview Components Figure 2.1 - Overview Cradle bar for flying ................... 1 piece SAF-connector with Double Stud + splint ............2 pieces Shackle SK10....................1 piece... -
Page 8: Technical Data
Assembly Instructions CBQ30 3. Technical data Data sheet Maximum load capacity 6x VERA S30 Maximum load capacity at 3x VERA S30 cardioid mode Dimensions (h x w x d) 753 x 106 x 8 mm [29.65 x 4.17 x 0.31 in] Weight 2,7 kg [5.95 lbs]... -
Page 9: Commissioning
4. Commissioning Setup The CBQ30 cradle bar for flying is designed for hanging operation. TW AUDiO provides a wide range of accessories to securely attach the swivel bracket. Please note that setting up the CBQ30 cradle bar for flying always requires two persons! -
Page 10: System Setup Cbq30 To Vera S30 Loudspeaker
General safety instructions for setting up this rigging variant: Use a shackle that is designed according to the payload for each system setup. WARNING Fasten the CBQ30 cradle bar for flying with a shackle and chain hoist according to the middle pin point. WARNING For the secondary safety component, the respective national electrotechnical regulations apply. - Page 11 Double Studs with the safety locking splints attached to safety wire ropes! WARNING Check that all Double Studs are engaged and that they have been secured with safety locking splints! WARNING CBQ30 BLT24 6x VERA S30 BLT24 BLT24 BLT24 BLT24 Figure 4.3 - System setup CBQ30 with VERA S30 loudspeaker...
-
Page 12: System Setup Cbq30 To Vera S30 Loudspeaker - Cardioid Mode
WARNING Use a shackle that is designed according to the payload for each system setup. WARNING Fasten the CBQ30 cradle bar for flying with a shackle and chain hoist according to the middle pin point. WARNING For the secondary safety component, the respective national electrotechnical regulations apply. - Page 13 Check that all Double Studs are engaged and that they have been secured with safety locking splints! WARNING CBQ30 VERA S30 BLT24 VERA S30 rotated BLT24 VERA S30 Figure 4.4 - System setup CBQ30 with VERA S30 loudspeaker - cardioid mode...
-
Page 14: Transport And Storage
This is why the product should be transported in a safe, careful, dry and largely dust-free manner. The following accessory parts for the cradle bar for flying are available from TW AUDiO: • Shackle SK10 • Boxlink connector wire rope BLT24 •... -
Page 15: Ce Conformity Declaration
Assembly Instructions CBQ30 6. CE Conformity Declaration Copy and translation of the original CE Conformity Declaration: We hereby declare that the below-referenced components by virtue of their design and con- struction, and in the configuration placed on the market by us, satisfy the safety and health requirements of the applicable EC directives. - Page 16 Assembly Instructions CBQ30 TWAMBO GmbH Karl-Hofer-Str. 42 14163 Berlin Germany Phone: + 49 (0) 71 41-48 89 89 0 Fax: + 49 (0) 71 41-48 89 89 99 E-Mail: info@twaudio.de WWW: www.twaudio.de...
