- Page 1 Assembly Instructions...
- Page 2 If you lend your product to another party, inform that party of the safety-related operating pro- cedures and hand over this assembly guide. If you require additional copies of this manual, you can obtain them free of charge from TW AUDiO or download them from www.twaudio.de Instructions in this user manual...
- Page 3 Assembly Instructions CBL Notes on the products Before using the device, carefully read the assembly instructions and keep it with the Read manual CBL cluster plate. before use! General information Assembly instructions: OM-CBL Version 2.0 en, 05/2022 © by TWAMBO 2022; all rights reserved.
-
Page 4: Table Of Contents
Assembly CBL to M6 loudspeaker on HSF ............10 Assembly CBL to M6 or M8 loudspeaker on HSA..........11 Assembly CBL to M6 or M8 loudspeakers at DHST ..........13 5. Transport and storage ....................14 6. CE Conformity Declaration .................... 15... -
Page 5: Safety | Intended Use
Damage caused by improper use is not covered by TWAMBO. Before every operation, check the scope of delivery of the CBL cluster plate for its complete- ness and ensure that all parts are in perfect condition. The scope of delivery includes specified components. Only use the recommended and cer- WARNING tified components. - Page 6 Assembly Instructions CBL The payload of the CBL cluster plate is designed of two M6 or two M8 loudspeaker. Do not exceed this payload. WARNING Before mounting the CBL cluster plate check that e.g. tripods and trussus are capable to carrying the payload of the components.
-
Page 7: Overview
Assembly Instructions CBL 2. Overview Components Figure 2.1 - Overview Hexagon screw M10 x 20................2 pieces Cluster plate CBL ....................1 piece... -
Page 8: Technical Data
Assembly Instructions CBL 3. Technical data Data sheet Maximum load capacity 2x M6 or 2x M8 Dimensions (h x w x d) 42 x 180 x 6 mm [1.65 x 7.09 x 0,24 in] Weight 0,4 kg [0.9 lbs] Surface... -
Page 9: Commissioning
4. Commissioning Setup The CBL cluster plate is designed for the hanging and stacking operation. TW AUDiO provi- des a wide range of accessories to securely attach the swivel bracket. Please note that setting up the system structures always requires two persons! -
Page 10: Assembly Cbl To M6 Loudspeaker On Hsf
Assembly Instructions CBL Assembly CBL to M6 loudspeaker on HSF Mount two M6 loudspeaker with CBL cluster plate and the HSF pole mount flange on the tripod. Make sure that you use suitable fastening material and that the connections are set... -
Page 11: Assembly Cbl To M6 Or M8 Loudspeaker On Hsa
Assembly CBL to M6 or M8 loudspeaker on HSA Mount two M6 or two M8 loudspeaker with CBL cluster plate and the HSA pole mount adap- tor on the tripod. Make sure that you use suitable fastening material and that the connections... - Page 12 Mount positions 1 and 2 (see figure 2.1) on top and bottom of the M6 or M8 loudspeakers as shown in figure 4.5.1 and 4.5.2. NOTE Figure 4.5.1 - Assembly CBL to M6 Lautsprecher on HSA Figure 4.5.2 - Assembly CBL to M6 Lautsprecher on HSA...
-
Page 13: Assembly Cbl To M6 Or M8 Loudspeakers At Dhst
Assembly CBL to M6 or M8 loudspeakers at DHST Attach the DHST Doughty Halfcoupler Slimline to the hole in the middle of the CBL cluster plate when using the CBL cluster plate on trusses. Make sure that the connec- tions are set firmly and correctly! WARNING Mount positions 1 and 2 (see figure 2.1) on top and bottom of the M6 or M8 loudspeakers as... -
Page 14: Transport And Storage
For this reason, the loudspeakers should be transported and stored in a safe, careful, dry and largely dust-free manner. The following accessory parts for the swivel bracket are available from TW AUDiO: • Hexagon screw M10 x 20 •... -
Page 15: Ce Conformity Declaration
Assembly Instructions CBL 6. CE Conformity Declaration Copy and translation of the original CE Conformity Declaration: We hereby declare that the below-referenced components by virtue of their design and con- struction, and in the configuration placed on the market by us, satisfy the safety and health requirements of the applicable EC directives. - Page 16 Assembly Instructions CBL TWAMBO GmbH Karl-Hofer-Str. 42 14163 Berlin Germany Phone: + 49 (0) 71 41-48 89 89 0 Fax: + 49 (0) 71 41-48 89 89 99 E-Mail: info@twaudio.de WWW: www.twaudio.de...
