Chapter 5. Hardware related
5.6 Production Test
5.6.1 Why can some modules download firmware normally when using DIO/DOUT, but
encounter program abnormality when using QOUT/QIO?
• Firstly, please check the modes supported by flash in the module and whether the module routing meets the
requirements of modes.
• Secondly, please check the QE bit of the status register of flash, which determines whether the flash supports
the QUAD mode or not.
• Different ESP chips/modules use flashes from different manufacturers. Some flashes have QE disabled by
default. Thus, it is necessary to check whether the flash supports Quad mode through actual testing.
• When ROM boots a second stage bootloader, the secondary read will fail if the configuration parameters are
read in the QIO mode because the QE bit is disabled.
• It is recommended to program firmware in the DIO mode and to configure the QIO mode in menuconfig.
The configuration enables the QE bit in the second stage bootloader and then boots the app bin to use the
QUAD mode.
5.6.2 How to get the production test tool?
CHIP: ESP32 | ESP8266
• Please click
production test tool
5.6.3 When I use the esptool.py
user-defined MAC address, why is the MAC address read by the esptool.py
read_mac command still factory default?
• The esptool.py read_mac command can only read the MAC address written in eFuse BLOCK0 by
default, but the user-defined MAC address written with the esptool.py burn_custom_mac command
is in eFuse BLOCK3. You may use the espefuse.py get_custom_mac command to check the MAC
address written to eFuse BLOCK3.
• For more information, please refer to
5.6.4 When downloading bin files to ESP32-WROVER-E (16 MB flash) using Flash
Download Tool, multiple separate bin files can be downloaded successfully, but
downloading the combined firmware (12 MB) failed. Why?
Since the combined firmware is mostly "0xFF"with relatively high compression rate, the amount of
data after decompression would be relatively large for the same length of compressed data, resulting in
a timeout error (default 7 seconds) after a long download time. To solve this issue, in Flash Download
Tool, go to configure > esp32 > spi_download, and disable the compression configuration
option as follows:
compress
=
False
no_compress
=
True
Espressif Systems
to download.
burn_custom_mac command to write the
esptool
documentation.
168
